Wet-Type Fine Particle Level Intensive Magnetic Separator-Separating Equipment1.rich ore concentrate
2.separate,remove Fe
Wet-Type Fine Particle Level Intensive Magnetic Separator-Separating Equipment
The Scope of Application
It is widely used in mineral separation, coal washing and chemical sectors for wet classifying strong magnetic mineral of size 0-6mm, and the mineral are divided into two kinds of products: magnetic and non-magnetic material. The specific susceptibility of its separating strong magnetic minerals should be no less than 3000*10-6cm/g, which belongs to this type of minerals are magnetite, magnetic pyrite etc.
Technical Data Of Wet Magnetic Separator
model |
Drum size(Diameter×Length)(mm) |
Magnetic induction strength of magnetic surface(mT) |
Disposal capacity |
Power(KW) |
Rotary speed(r/min) |
weight(KG) |
instruction |
|||
|
Geometric center value Of pole |
Average value of sweeping field |
The highest magnetic induction intensity |
T/h |
M3/h |
||||||
CTS(N/B)-46 |
400×600 |
|
130 |
240 |
1-3 |
5 |
1.1 |
45 |
600 |
|
CTS(N/B)-66 |
600×600 |
|
145 |
240 |
1-10 |
16 |
1.1 |
40 |
750 |
Permanent-magnetic |
CTS(N/B)-69 |
600×900 |
|
145 |
240 |
8-5 |
24 |
1.1 |
40 |
830 |
|
CTS(N/B)-612 |
600×1200 |
|
145 |
240 |
10-20 |
32 |
2.2 |
40 |
990 |
|
CTS(N/B)-618 |
600×1800 |
|
145 |
240 |
15-30 |
48 |
2.2 |
40 |
1330 |
|
CTS(N/B)-712 |
750×1200 |
120 |
155 |
|
15-30 |
48 |
3 |
35 |
1500 |
|
CTS(N/B)-718 |
750×1800 |
120 |
155 |
240 |
20-45 |
72 |
3 |
35 |
2100 |
Permanent magnetic |
CTS(N/B)-918 |
900×1800 |
148 |
165 |
240 |
25-55 |
90 |
4 |
28 |
2900 |
|
CTS(N/B)-924 |
900×2400 |
148 |
165 |
240 |
35-70 |
110 |
4 |
28 |
3500 |
|
CTS(N/B)-1028 |
1050×1800 |
148 |
165 |
240 |
40-75 |
120 |
5.5 |
22 |
4000 |
|
CTS(N/B)-1021 |
1050×2100 |
148 |
165 |
240 |
45-88 |
140 |
5.5 |
22 |
4500 |
|
CTS(N/B)-1024 |
1050×2400 |
148 |
165 |
240 |
52-100 |
130 |
5.5 |
22 |
5000 |
Left and right |
CTS(N/B)-1030 |
1050×3000 |
160 |
240 |
240 |
65-125 |
200 |
7.5 |
22 |
6200 |
|
CTS(N/B)-1218 |
1200×1800 |
148 |
165 |
240 |
47-90 |
140 |
5.5 |
19 |
5800 |
|
CTS(N/B)-1224 |
1200×2400 |
148 |
165 |
240 |
82-120 |
192 |
7.5 |
19 |
6200 |
|
CTS(N/B)-1230 |
1200×3000 |
148 |
165 |
240 |
80-150 |
240 |
7.5 |
19 |
6200 |
|
CTS(N/B)-1530 |
1500×3000 |
180 |
240 |
240 |
90-170 |
270 |
11 |
14 |
8100 |
|
CTS(N/B)-1540 |
1500×4000 |
180 |
240 |
240 |
115-220 |
350 |
11 |
14 |
9300 |
|
General Structure Of Wet Magnetic Separator
Advantages:
1.Simple structure
2.Large Processing Capacity
3.Convenient operation
4.Easy maintenance
Three Types of Tank
The one cylinder can be equipped with three types of tank, namely downstream launder, countercurrent launder and semi-countercurrent launder.
Technological Drawing
About Us
Installation In Customer's Factory
Certificate
