Specifications
CTG Series Medium Intensity Permanent Magnetic Rotary Drum1.remove Fe
2. used for conveyor belt
3.easy operation
4.easy ins
CTG Series Medium Intensity Permanent Magnetic Rotary Drum
Application
They are widely used in metallurgy, abrasive, corundum, non metallic minerals, refractory materials, mine, food, chemical industry, glass, building materials and so on. (Semi magnetic and magnetic structures) They are used to purify the powdered, granular and bulk materials, or to recycle iron. They play a reliable function by preventing crushers, grinders and pressers from wearing and being broken. They can satisfy the major users’ requirements of removing iron large-deep in strong magnetic field.
Technical Parameters Of Magnetic Rotary Drum
|
Model Type for Reference |
Cylinder Diameter (mm) |
Fit Width(mm) |
Cylinder Length(mm) |
Magnetic Induction Intensity of the Surface (GS) |
Rolling Speed (r/min) |
Remove Iron Powder from powdered materials
|
Remove Iron Impurity from Material Pieces (T/h) |
Weight (KG) |
CTG-32/40 |
320 |
400 |
500 |
3000 |
28-35 |
0.8 |
10 |
120 |
CTG-32/50 |
320 |
500 |
600 |
3000 |
1 |
15 |
150 |
|
CTG-40/50 |
400 |
500 |
600 |
3000 |
2 |
20 |
240 |
|
CTG-50/50 |
500 |
500 |
600 |
3000 |
3.5 |
30 |
360 |
|
CTG-32/65 |
320 |
600 |
750 |
3000 |
2 |
20 |
210 |
|
CTG-40/65 |
400 |
600 |
750 |
3000 |
2.8 |
30 |
350 |
|
CTG-50/65 |
500 |
600 |
750 |
3000 |
4.5 |
40 |
420 |
|
CTG-63/65 |
630 |
600 |
750 |
3000 |
7 |
45 |
830 |
|
CTG-40/80 |
400 |
800 |
950 |
3000 |
8 |
55 |
470 |
|
CTG-50/80 |
500 |
800 |
950 |
3000 |
10 |
65 |
600 |
|
CTG-63/80 |
630 |
800 |
950 |
3000 |
10 |
80 |
800 |
|
CTG-80/80 |
800 |
800 |
950 |
4000 |
12 |
100 |
980 |
|
CTG-63/100 |
630 |
1000 |
1150 |
3500 |
12 |
120 |
1200 |
|
CTG-80/100 |
800 |
1000 |
1150 |
4000 |
11.5 |
140 |
1300 |
|
CTG-100/120 |
1000 |
1200 |
1400 |
4000 |
20 |
180 |
1580 |
|
CTG-152/140 |
1250 |
1400 |
1600 |
4000 |
30 |
250 |
1950 |
Working Principle
The magnetic pulley is made of high quality stainless steel & high B content of rare earth. It can be installed to the motor, which is equipped on the conveyor system, so that the magnetic pulley and conveyor belt form the magnetic splitter. The material contains ferrous will be separated from minerals as a result of the magnetism of the drum when the mineral contains ferrous comes through magnetic splitter.
General Structure Of Magnetic Rotary Drum
Installation In Customer's Factory
