Ceramic Vacuum Rotary Drum Filter for Coal Production Line in China
- 30 Set / Sets per Month
- Lianyungang shanghai qingdao
- T/T
-
Durable Ceramic Vacuum Filter for Vacuum Filter Material Gold Tainlings
-
High Quality Rotary Vacuum Filter from alibaba China Supplier
-
2016 Newest Rotary Vacuum Filter Ceramic Plate Vacuum Filtration System for Dewatering and Dehydration
-
Ceramic Vacuum Disc Filter Using Vacuum Filtration System Effiectively
-
High Quality Vacuum Rotary Drum Ceramic Filter for Ore Slurry Separation
-
BoYun New Techn Ceramic Filter Vacuum Rotary Filter for Waste Acid Treatment
Product Details
| Place of Origin: | Jiangsu, China | Brand Name: | BoYun | Model Number: | BY-21 |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
flat rack or up to the customer' s demands
Product Description
Model Name: | BY Series |
Filtering area: | 1-120 m2 |
Filtering elements: | Ceramic plates |
Self Clean: | Acid Washing and Ultrasonic Device |
Discharging of cake: | Auto-discharging with scraper and belt conveyer |
Discharging of filtrate: | Vacuum Liquid Discharging Tank |
Scope of application
The ceramic vacuum disc filter is widely used for dewatering slurry ore, clean coal, waste coal and others, it also can be used for solid-liquid separation in metallurgy, chemical industry, environmental pollution, petroleum and sewage treatment. The fineness of materials is from -200to-450mesh and a variety of superfine materials.
Different project site
Specification of BY series
Specification | Filter area (m2) | Disc Quantity (pcs) | Filter plate diameter(m) | Main size(length*width*height) (m) | Weight (T) | Power (KW) | Operating power (KW) | Volume of tank |
BY-1 | 1 | 1 | 1.52 | 1.7x1.5x1.5 | 1.4 | 5.28 | <3.08 | 0.2 |
BY-2 | 2 | 2 | 1.52 | 1.9x1.5x1.5 | 2.1 | 5.4 | <3.2 | 0.3 |
BY-4 | 4 | 2 | 1.52 | 2.5x2.5x2.5 | 2.6 | 6 | <3.8 | 0.9 |
BY-6 | 6 | 2 | 1.52 | 2.8x2.9x2.5 | 2.9 | 7.3 | <5.1 | 1.4 |
BY-9 | 9 | 3 | 1.52 | 3.1x2.9x2.5 | 3.5 | 12.36 | <8.36 | 1.9 |
BY-12 | 12 | 4 | 1.52 | 2.96x2.9x2.5 | 4.5 | 13.08 | <9.08 | 2.4 |
BY-15 | 15 | 5 | 1.92 | 3.56x2.9x2.5 | 4.9 | 13.8 | <9.8 | 2.9 |
BY-18 | 18 | 6 | 1.92 | 3.86x2.9x2.5 | 5.3 | 14.52 | <10.52 | 3.4 |
BY-21 | 21 | 7 | 1.92 | 4.16x2.9x2.5 | 5.7 | 15.24 | <11.24 | 3.9 |
BY-25 | 25 | 5 | 1.92 | 3.62x3.45x2.95 | 6.1 | 16.7 | <12.7 | 4.4 |
BY-30 | 30 | 6 | 1.92 | 3.92x3.45x2.95 | 6.9 | 19.7 | <14.2 | 5.3 |
BY-35 | 35 | 7 | 1.92 | 4.22x3.45x2.95 | 7.7 | 20.05 | <14.56 | 6.2 |
BY-40 | 40 | 8 | 1.92 | 4.52x3.45x2.95 | 8.5 | 22.06 | <16.22 | 7.1 |
BY-45 | 45 | 9 | 1.92 | 4.82x3.45x2.95 | 9.3 | 25.72 | <18.22 | 8 |
BY-60 | 60 | 12 | 2.06 | 5.77x3.45x2.95 | 11.7 | 30.46 | <22.46 | 11 |
BY-80 | 80 | 16 | 2.1 | 6.97x3.45x2.95 | 14.9 | 43.78 | <28.78 | 14 |
BY-90 | 90 | 15 | 2.1 | 6.7x4.2x3.5 | 15.2 | 51.3 | <36.3 | 16 |
BY-102 | 102 | 17 | 2.1 | 7.3x4.2x3.5 | 17.6 | 60.9 | <38.9 | 18 |
BY-120 | 120 | 20 | 2.1 | 8.2*4.2*3.5 | 21.2 | 66.22 | <44.22 | 19 |
(Just for reference)
Benefits of ceramic filter
.Large processing capacity, energy saving is obvious
.Fully automatically, perfect automatic protection function
.Small occupied area, low transportation cost
. Easy installation and maintenance
. Reliable structure and long lifespan
Working sketch map
General structure
About us
Certificate
Questions
1.what is the raw material do you want to process? Iron ore, copper ore, or others
2.What is the feed concentration of raw material?
( usually for mineral processing 60%200mesh,for the cement 350mesh)
3.What is the capacity per hour do you need? wet type or dry type?
Any requirements and questions please fell free to contact us:+86-18052312057, Whatsapp:+86-18052312057
Company Profile
Lianyungang Boyun Machinery Co., Ltd. is a professional manufacturer of mineral machinery, specialized in the design, research & development, manufacture & sales. We have owned 60 products including feeding, cracked, transportation, ore grinding, classification, flotation, concentration, drilling & magnetic separation. Those are widely used in mines, drilling and engineering construction.
Boyun is located in Donghai County, Lianyungang City. There are 10 engineers & 100 staff members more or less. Boyun pays much attention to product quality, and actively follows ISO9001 standards. We have many advanced performance test equipment and continuously make improvements to our quality assurance system. Quality service is considered as an important part of our product quality, and we honor our commitments we make before and after sales. We take seriously on every machine production so that we make sure it meets demand of our customers. Besides, we also can supply our customers mineral separation program design, mineral separation technological process design and standard & non-standard design. Donghai has beautiful scenery and beaches, convenient transportation that included harbors, an airport, railroads, and highways.
Welcome friends all over the world to visit our factory.
