530Ton Mix Color Injection Molding Machine

530Ton Mix Color Injection Molding Machine thumbnail-1
530Ton Mix Color Injection Molding Machine photo-1
US$ 1 - 2 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Preform Injection
Style:
Horizontal
Contact Supplier Request Quote Chat Now
Ningbo Ongo Precision Injection Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Preform Injection
Style Horizontal
Brand Name ONGO
Model Number ZSH110
Place of Origin Zhejiang, China
Plastic Type Thermoplastic
Automatic Yes
Injection Weight 148g,83g
Injection Rate 89g/s,73g/s
Clamping Force 1100KN
Opening Stroke 350mm
Power(W) 35.8KW
Certification ISO9001,CE
After-sales Service Provided Engineers available to service machinery overseas

ZSH 110ton--650ton Mix Color Injection Molding Machine Parameters Table



ZSH110 mix color Injection molding machine
Item   ZSH110
Injection Unit   Main injection unit Side injection unit
Screw diameter mm 35 30
Shot volume cm3 163 92
Injection weight g 148 83
Injection rate g/s 89 73
Injection pressure Mpa 219 170
Screw speed rpm 210 185
Clamping Unit
Clamping force KN 1100
Open stroke mm 350
Space between tie bars(W*H) mm 370*370
Max.mould height mm 380
Min.mould height mm 150
Ejector stroke mm 100
Ejector force KN 38
Others
Max.pump pressure Mpa 16 16
Pump motor power kw 22
Heating power kw 7.5 6.3
Machine dimension(L*W*H) m 4.68*1.25*1.90
Oiltank cubage L 230
Machine weight t 3.4





ZSH140 mix color Injection molding machine
Item   ZSH140
Injection Unit   Main injection unit Side injection unit
Screw diameter mm 42 30
Shot volume cm3 277 92
Injection weight g 252 83
Injection rate g/s 115 73
Injection pressure Mpa 171 170
Screw speed rpm 185 185
Clamping Unit
Clamping force KN 1400
Open stroke mm 380
Space between tie bars(W*H) mm 420*420
Max.mould height mm 450
Min.mould height mm 160
Ejector stroke mm 120
Ejector force KN 50
Others
Max.pump pressure Mpa 16 16
Pump motor power kw 22
Heating power kw 9.3 6.3
Machine dimension(L*W*H) m 4.72*1.20*2.00
Oiltank cubage L 270
Machine weight t 4



ZSH170 mix color Injection molding machine
Item   ZSH170
Injection Unit   Main injection unit Side injection unit
Screw diameter mm 45 30
Shot volume cm3 357 92
Injection weight g 325 83
Injection rate g/s 160 73
Injection pressure Mpa 177 170
Screw speed rpm 180 185
Clamping Unit
Clamping force KN 1700
Open stroke mm 435
Space between tie bars(W*H) mm 470*470
Max.mould height mm 520
Min.mould height mm 180
Ejector stroke mm 140
Ejector force KN 50
Others
Max.pump pressure Mpa 16 16
Pump motor power kw 30
Heating power kw 12.3 6.3
Machine dimension(L*W*H) m 5.40*1.30*.2.05
Oiltank cubage L 300
Machine weight t 6



ZSH230 mix color Injection molding machine
Item   ZSH230
Injection Unit   Main injection unit Side injection unit
Screw diameter mm 50 38
Shot volume cm3 490 192
Injection weight g 446 175
Injection rate g/s 154 105
Injection pressure Mpa 168 186
Screw speed rpm 155 230
Clamping Unit
Clamping force KN 2300
Open stroke mm 475
Space between tie bars(W*H) mm 520*520
Max.mould height mm 530
Min.mould height mm 200
Ejector stroke mm 140
Ejector force KN 70
Others
Max.pump pressure Mpa 16 16
Pump motor power kw 30
Heating power kw 14.8 7.5
Machine dimension(L*W*H) m 5.50*1.35*2.22
Oiltank cubage L 300
Machine weight t 7



ZSH270 mix color Injection molding machine
Item   ZSH270
Injection Unit   Main injection unit Side injection unit
Screw diameter mm 55 38
Shot volume cm3 641 192
Injection weight g 583 175
Injection rate g/s 227 105
Injection pressure Mpa 169 186
Screw speed rpm 180 210
Clamping Unit
Clamping force KN 2700
Open stroke mm 540
Space between tie bars(W*H) mm 570*570
Max.mould height mm 550
Min.mould height mm 200
Ejector stroke mm 150
Ejector force KN 70
Others
Max.pump pressure Mpa 16 16
Pump motor power kw 37
Heating power kw 16.8 7.5
Machine dimension(L*W*H) m 5.90*1.60*2.25
Oiltank cubage L 380
Machine weight t 8





ZSH360 mix color Injection molding machine
Item   ZSH360
Injection Unit   Main injection unit Side injection unit
Screw diameter mm 70 45
Shot volume cm3 1289 318
Injection weight g 1175 289
Injection rate g/s 368 132
Injection pressure Mpa 170 148
Screw speed rpm 190 180
Clamping Unit
Clamping force KN 3600
Open stroke mm 660
Space between tie bars(W*H) mm 670*670
Max.mould height mm 720
Min.mould height mm 250
Ejector stroke mm 160
Ejector force KN 70
Others
Max.pump pressure Mpa 16 16
Pump motor power kw 37 18.5
Heating power kw 24.8 12.3
Machine dimension(L*W*H) m 7.21*1.90*2.34
Oiltank cubage L 620
Machine weight t 12.5



ZSH460 mix color Injection molding machine
Item   ZSH460
Injection Unit   Main injection unit Side injection unit
Screw diameter mm 80 45
Shot volume cm3 1960 318
Injection weight g 1784 289
Injection rate g/s 449 132
Injection pressure Mpa 152 148
Screw speed rpm 160 180
Clamping Unit
Clamping force KN 4600
Open stroke mm 740
Space between tie bars(W*H) mm 770*770
Max.mould height mm 780
Min.mould height mm 250
Ejector stroke mm 200
Ejector force KN 110
Others
Max.pump pressure Mpa 16 16
Pump motor power kw 37 18.5
Heating power kw 30.7 12.3
Machine dimension(L*W*H) m 8.00*2.15*3.00
Oiltank cubage L 720
Machine weight t 16



ZSH650 mix color Injection molding machine
Item   ZSH650
Injection Unit   Main injection unit Side injection unit
Screw diameter mm 95 45
Shot volume cm3 3048 318
Injection weight g 2774 289
Injection rate g/s 612 132
Injection pressure Mpa 165 148
Screw speed rpm 145 180
Clamping Unit
Clamping force KN 6500
Open stroke mm 870
Space between tie bars(W*H) mm 880*880
Max.mould height mm 900
Min.mould height mm 350
Ejector stroke mm 250
Ejector force KN 150
Others
Max.pump pressure Mpa 16 16
Pump motor power kw 45 37
Heating power kw 42.8 12.3
Machine dimension(L*W*H) m 10.20*2.24*2.71
Oiltank cubage L 1100
Machine weight t 28





Feature



  • The energy saving electromagntic heating system
  • Linking connecting rod
  • Platen center is thick enough----New utility model patent:200920121070.7
  • Enhanced stationary platen------New utility model patent:200920122627.9
  • Special customized optimized control system------Design patent:200930142016.6
  • Injection preplastication seat with oil copper sleeve
  • Colsed base structure
  • Automatic mould adjustment
  • Sealed structure with cone surface
  • Sppray plastic in oil tank----New utility model patent:200920121071.1
  • Double moveble hydraulic cyliders tighening structure
  • Copper bush with hgih quality
  • Number conersion linkage stucture
  • The device to transit thin lubrication oil in colume style
  • Screw rotational speed detection
Factory Customer

530Ton Mix Color Injection Molding Machine530Ton Mix Color Injection Molding Machine530Ton Mix Color Injection Molding Machine

530Ton Mix Color Injection Molding Machine

530Ton Mix Color Injection Molding Machine530Ton Mix Color Injection Molding Machine









Participate in exhibition 530Ton Mix Color Injection Molding Machine



Authenticate

530Ton Mix Color Injection Molding Machine



Our Customer

530Ton Mix Color Injection Molding Machine

We offer  one year warranty service machines for you without screw,and  specialize in providing  a full set of equipment solutions with mould and  auxiliary for our  customer .
