Home > Products > Blow molding machine > Plastic Balls Blow Molding Machine
Plastic Balls Blow Molding Machine
- Shanghai
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | APOLLO | Model Number | ABLB55 | |
| Certification | CE |
Product Description
Specifications
Plastic balls blow molding machineHigh-speed output 8500 pcs/h
MOOG parison controller
Stable movement reliable function
Automatic extrusion blow molding machine ABLB55
CE certification About us
electronic parts |
|
Name | Trader |
Micro computer control system | Japanese MITSUBISHI |
Temperature Controller | TAIWAN YANHUA PID |
Auxiliary Relay | OMRON |
contactor | Schneider from France |
Electric motor | Three phase 220V or 380V |
Power Source | TAIWAN MEANWELL |
Transducer | TAIDA FROM CHINA |
hydraulic parts |
|
Name | Trader |
Oil pump | TAIWAN HIGH-TECH |
Valve | TAIWAN JINSHUN/YUKEN |
Oil pump and connection | TAIWAN JINSHUN/YUKEN |
Sealed part | HALLITE |
air control system |
|
Name | Trader |
Cylinder | AIRTAC |
Air Valve | FESTO |
30% down payment paid at signing this contract by T/T , and the balance of 70% paid before shipment by T/T or irrevocable L/C.
Delivery no later than 40 days, after we received the deposit.
Related technical parameter:
Max. Product volume | 3.5 liters |
Dry cycle | 1100pc/h |
Screw diameter | 55mm |
Screw L/D ratio | 24 L/D |
Screw drive power | 15 KW |
Screw heating capacity | 5-6 KW |
No.of heating zone | 3 zones |
Output of HDPE | 60 KG/H |
Oil pump drive power | 7.5 KW |
Clamping force | 45 KN |
Max.size of mold | 148-508mm |
Mold stroke | 320X360mm |
Max.die diameter | 140mm |
Blowing pressure | 0.6mpa |
Air volume | 0.5 M³/MIN |
Cooling water pressure | 0.3mpa |
Water consumption | 40 L/MIN |
