Product Details
Brand Name: | Better | Model Number: | SHP4-CNC-3000G |
Product Description
CNC vertical 4 point welding pvc window machine,Model:SHP4-CNC-3000G
This machine is the special equipment for the welding of plastic profiles and rectangle welding in a ringlet with
advanced technology, stability and compact structure.pneumatic driving and the imported complete line pain
gives the machine easy operation and high accuracy, The computer programming control enlarged there liability and ensures the high efficiently,This machine is suitable for large volume production,The pneumatic driving system uses the imported parts of excellent performance and longevity,The controlling part are imported
computer for industry the driving system uses the imported step by step motor and imported timing belt which
ensure the locating accuracy and longevity.
Working Air Pressure | 0.5~0.8Mpa |
Air Consumption | 200L/min |
Power Supply | As required |
Input Power | 11kw |
Welding Dimension Range | 300x300mm~1800x3000mm |
Welding Profile Height | 20~120mm |
Welding Profile Width | ≤120mm |
Outside Dimension | 5500x3500x1200mm |
Weight(about) | 3000kg |
Welding machines---One / two / three / four head
Cutting machines---One / two head
V notch saw,Glazing bead saw,Water slot milling machine
End milling machine,lock hole and copy router milling machine
Corner cleaning machine,corner cleaning tools
