4 Platens Rotating Pulp Molding Machine for Shoe Stretcher
* Introduction
4 Platens Rotating Pulp Molding Machine for Shoe Stretcher
This model is four planes industrial package machine that after many years of corporate research and development. It is the first patented production in China. The height of the production can be 20mm, the speed of the forming system is twice as traditional way.
* Advantages
| 1 | Molds is national patented design. |
| 2 | It is It controlled by PLC, can use touch screen control & manual control. |
| 3 | |
| 4 | The Cam runs 4 times forming and transferring the production. |
* Specification
Mold platen size |
1200×500mm(mold size≤1100×420mm) |
Mold |
forming mold (1pc) + transferring mold (1pcs) + hot-pressing mold (2pcs) |
Power & voltage & frequency |
4KW(6KW×4) 380V±20% 50/60HZ |
Timing Mode |
PLC control (0-5times/min adjustable) |
Electrical control system voltage & frequency |
220V±10% 50/60HZ |
Production methods |
automatic |
Pressure of compressed air |
0.5 — 0.8 MPa |
Vacuum negative pressure |
-0.03 — -0.08 MPa |
Oil cylinder working range |
300 kgf/cm2 |
Height of product |
10-200mm |
Capacity |
13-15 times/min |
* Application
Our company is a professional manufactuer on various kind of pulp molding machine in China for over 30 years.With updated machinery and skilled staffs we have supplied stable high quality products to customers all over the world.
Our experianced engineers and exporting team will answer your inquiry or email at the first time,and providing professional service from factory visiting,ordering to deliver goods and after-sales service.
Our guarantees: providing the best services in order to satisfy every reasonable demands of customers, providing complete services including factory design, installment and debugging of machine until accomplishment of the conforming products.
We supply customers all over the world with best quality products:
1. Pulp molding product lines such as egg tray/egg carton production line, fruit tray production line, pulp molding industrial package production line.
2. Molds for pulp molded products.
Pre-sales services
* any concerns of our machine by email/phone will be replied ASAP within 24 hours
* according to the customers’ requirements and circumstance to make the best egg tray production line design
* cost/benefit analysis
* to support factory layout
* desigh and make egg tray sample (charge, but if you ordering can offset the purchase price)
In the sale of services
* we are in charge of installing,debugging and training
* technical guidance of frequently asked questions
After-sales service
* one year guarantee for whole machine except of quick-wear part
* 24 hours technical support by email/phone
* calling, network or door-to-door service
* use friendly English software, user manual and detailed Videos/CD
Packaging
Wrapped with corrugated sheets ,then fixed by steel wires in the container.
Shipping
1. Different machine models, different container size.
2. We accept any kind of transportation.
3. We provide timely logistics information for you.
