SH-1000A pulp molding production line scheme
1. Pulping system
machie |
hydraulic pulper |
high-freqency vibration sieve frame |
pulp pump |
strengthening of priming pump |
control cabinet for pulp system |
agitator |
specification |
1.0M3 |
0.9M2 |
standard component(made in china) |
standard component (made in china) |
C2 |
standard component (made in china) |
motor |
11KW |
3.0KW |
3*3KW |
3KW |
|
3*1.5KW |
2. Forming system
machine |
tiltering forming machine |
molds |
vacuum pump |
screw air compressor |
vacuum buffer tank |
air compressor storage tank |
white water pump |
high-pressure water pump |
refiner machine |
specification |
size: 1300*520mm forming efficiency:5-7cycles/min
|
forming mould size: 295*295mm materials: plastic quantity:6pcs |
|
|
0.6M3 |
0.3 M3 standard component(made in china) |
standard component(made in china) |
standard component(made in china) |
standard component(made in china) |
motor |
|
|
18.5KW |
15KW |
|
|
2.2KW |
2.2KW |
|
3.Drying system
machine |
conveyor |
blower |
induced fan |
burner |
bellows |
tracked board |
fore dynamics |
postern dynamics |
chain |
heating box |
unit/quantity |
1 |
5 |
1 |
5 |
24 |
380 |
1 |
1 |
95M |
60 |
motor |
|
5*4KW |
2.2KW |
|
|
|
|
3KW |
|
|
ntrol cabinet for drying system , specification C3 and packing machine
our guarantee
We will be responsible for the instuction in installation, test running and training.
warranty: one year's repaire and maintainance since finishing the installation for free.
this business is definitely a profitable investment both for environment and the invester.
remark
| 1.Output: 800-1000pcs/h (equivalent to30-pack egg trays). | ||||||||||
| 2.Total Power: 101.1KW | ||||||||||
|
nsumption( /HOUR): water:120-150kg waste paper :60-75kg electricity:80-86kw 0# diesel oil:15-20kg natural gas:15-18kg LPG:10-15kg | ||||||||||
| 4.The above quotation doesn’t include the packing cost of large equipment. | ||||||||||
| 5. The way of payment:30% of the total amount of money signed in the contact must be paid as the contact | ||||||||||
| becomes effective, 65% of the total amount of money must be completed before delivery of equipment. | ||||||||||
| The rest 5% must be paid within 7 days after finishing all the installation. | ||||||||||
| 6. Delivery time: 40 working days after received deposit | ||||||||||
|
7.The design of technological process and plant arrangement will be provided according to the plant situation of the customer. | ||||||||||
| 8. workforce: 5-6people / working group | ||||||||||
| 9.we are in charge of installing,degugging and training, the total time is about 1 months | ||||||||||
| 10.buyer side should be responsible for two way flight tickets, local hotel and food charge, as well as $80 per day | ||||||||||
| for each technican as salary/subsidy | ||||||||||
| 11.Container: 1 40' HQ and 1 20'GP | ||||||||||
| 12.guarantee: repair and maintenance one year for free. |
Welcome to contact us for further information!
