A. The model of our waste tyre recycling pyrolysis oil plant:
| No. | Reactor size(mm) |
Weight(MT) |
Volume(M3) |
Capacity( MT/D) |
1 |
2200*2200*6000 |
27 |
23 |
5 |
2 |
2200*2200*6600 |
29 |
25 |
6 |
3 |
2600*2600*6000 |
32 |
32 |
8 |
4 |
2600*2600*6600 |
34 |
35 |
9 |
5 |
2800*2800*6000 |
35 |
37 |
10 |
6 |
2800*2800*6600 |
38 |
41 |
12 |
B. The technical parameter of waste tire recycling pyrolysis oil plant:
1 |
Model |
2200-6000 |
2200-6600 |
2600-6600 |
2800-6000 |
2800-6600 |
2 |
Capacity |
5 Ton/D |
6 Ton/D |
9 Ton/D |
10 Ton/D |
12 Ton/D |
3 |
Power |
8-11kw |
8-11kw |
12-17kw |
12-17kw |
12-17kw |
4 |
Material |
tyre/rubber/plastic |
||||
5 |
Structural form |
Horizontal rotation |
||||
6 |
Operating pressure |
Constant pressure |
||||
7 |
Reactor speed |
0.4 turn /minute |
||||
8 |
Mode of cooling |
Water cooling |
||||
9 |
Type of drive |
Internal gear drive |
||||
10 |
Noise dB(A) |
≤85 |
||||
11 |
Heating mode |
Direct heating |
||||
12 |
Dispatch period |
20 days after receiving the down payment |
||||
C. The main parts of waste tire recycling pyrolysis oil plant:
1) Rotatable reactor 10)Cooling pool 19) Water pump
2) Machine cove 11)Induced Draft fan
3) Main machine base 12) Speed reduce
4) Oil-gas separator 13)Dust removing system
5) Catalyst tower 14)Waste gas burners
6) Coil cooling system 15)Blowers
7) Light oil tank 16)Electric cabinet
8) Heavy oil tank 17)Pressure meter
9) Water sealing tank 18)Temperature meter
D. The flow chart of waste tire recycling pyrolysis oil plant:
Waste tyre broken → automatic feed → catalytic cracking → oil water separation → cooling liquid → carbon black emission
→ carbon black processing → crude oil → flammable gas recovery → flammable gas combustion → desulfuration removal.
E. 3D waste tyre recycling pyrolysis oil plant:
F. Delivery for waste tyre recycling pyrolysis oil plant:
G. The overseas installation for waste tyre recycling pyrolysis oil plant:
H. The waste tyre recycling pyrolysis oil factory:
The plant itself cover 200-300 square meters(length 20-30M ; Width 15M).
Add raw material stay, carbon black stay, big oil tank zone ,workers rest room and simple office. At least 600-800square meters.
1.Quality warranty period:
One year warranty for the chamber of the pyrolysis machines,and lifetime maintenance for complete set of machines. pay the double air tickets, accommodation and food.
2.According to the requirement of the buyer, our company sends engineers for installation and commissioning in buyer's site including the training of skills of buyer's workers on operation, maintenance, etc.
3. Supply layout according to buyer's workshop and land, civil works information, operation manuals, etc. to the buyer.
