Home > Products > Toilet Paper Production Line Series > C:CDH-1200 Slitting And Rewinding Machine For Kraft Paper
C:CDH-1200 Slitting And Rewinding Machine For Kraft Paper
- 30 Set / Sets per Month
- Xiamen China
- T/T Credit Card
- Semi Automatic Packing Line , Toilet Roll Packaging Machine Price
- Semi Automatic Packing Line , Toilet Roll Tissue Packaging Machine
- Semi Automatic Tissue Paper Packing Machine , Tissue Rolls Packing Machine
- Tissue Rolls Packing Machine , Automatic Packing Machine
- Tissue Roll Packing Machine , Semi Automatic Toilet Roll Packing Machine
- Manual Cutter for Cutting Paper , Paper Cutting Machine Small Size
Product Details
Condition: | New | Product Type: | Other, paper cutting and rewind | Processing Type: | Other, slitting and rewinding machine |
Place of Origin: | Fujian, China | Brand Name: | Chuangda | Model Number: | CD-1200 |
Voltage: | 380V 50HZ | Power(W): | 6 KW | Dimension(L*W*H): | 4200*2000*1200mm |
Weight: | 2000kg | Certification: | CE | Warranty: | 1 year, Lifelong maintenance |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
CDH-1200 Slitting And Rewinding Machine For Kraft Paper, corrugated board cutting machinery, sand-coated paper rewinder
1.Main Parameter:
Power supply | 380V 50HZ |
Installation capacity | 6.0 KW |
Designed production speed | 100m/min |
Stable production speed | 60-80m/min |
Product dimension | adjustable |
Minimum slitting width | 50mm |
Jumbo roll dimension | Ø1000×1200mm (Dia.×Width)(adjustable) |
Basis Weight | 80-800g/m2 |
Waster percent | ≤2% |
Machine dimension | 4.2×2.0×1.2m (L×W×H) |
Weight | 2.0T |
Spare part | Qty. |
Cutting blade | 10 pcs |
Tool kit | 1set |
2.Pictures of machine part
3.Pictures of final products:
4.Features:
1). The machine is used to slit and rewind kraft paper, corrugated board, sand-coated paper and all kind of packing material.
2). Belt drive, web tension control device.
3). It can be equipped with automatically load jumbo roll unit according to customers` demand.
4). It has the feature of rational structure, easy operation and simple maintenance.
5. Certificate:
CE
6.Pictures of our company:
Welcome to inquiry and welcome to our factory.
My Skype: carry383
