P: CD-380 Full Automatic Wet Tissue Packing Machine

 suitable for 5-120pcs/pack

 Power supply: 380V, 50HZ

Power: 8KW
Packing form: Pillow type
Production speed: 40--50packs/min
Product size (mm): (180-300)x(90-120)x(10-80) (L*W*H)
Control system: PLC control system, color touching screen
Net weight of machine: Approx. 1900KG
Machine size(mm): 5280*1000*2100mm (L*W*H)

Adopt PLC control, cutting as the length was set, working are more exact

Touching screen, the setting of parameter is convenient and fast, easier coperate

3 meters raw material conveying shelf

Electrical eye tracks automatically,

Date printing device,

Punching device,

Labeling device.

Adjustable bag-making equipment

With inserting corner device to make pillow type packing

Working flow

        Unrolling packing film—printing date—punching window hole on packing film— sticking label on window hole --- feeding wipes and forming bag — centre sealing---discharge air in the bag---end sealing and cutting—output finished products

Machine Introduction

     Suitable to pack big size wet wipes, pack pillow type, such as 30-120 pcs wet tissues/pack.

The machine is controlled by PLC. The width and the length of packing size can be adjusted on the machine. The operation of the machine is very easy

.
