Precisely small size analog/digital wattmeter
Specification
Brand new and high quality.
Measure energy(wh),charge(ah), power(w),current(A) and voltage(V).
Accurate & precise 0.01 A cuurrent and 0.01 V voltage resolutions.
Measures peak Amps, peak Watts(except for Doc Wattson) and Voltage minimum(sag).
Rugged- handles 50A continuous and 100 A peak at 60V.
14a ga., super fine stranded, high temperature, silicone rubber insulated wire.
Small & light with a tough plastic case available in several colors.
Acts like a wire so doesn't affect model's performance. Precision Alu-Chrom current sensing
resistor, with only 0.001 Ohms resistance and circuitry that draws only 7 mA.
USes DSP to increase ADC resolution and differential measurement amplifiers to increase
noise immunity.
Size:8.3cm x 4.7cm x 2cm - 3.27inch x 1.85inch x 0.79inch
Performance parameters
Color:Blue
Name : A(200200)680 – Watt Meter.
Voltage:(0)V-4V-60V 0.01V (Resolution).
Current:0-100 A peak 0.01A (Resolution).
Power:0-6554 W 0.1W (Resolution).
Charge:0-65 Ah 0.001Ah (Resolution).
Energy:0-6554 wh 0.1 Wh (Resolution).
Measurement Update period:400mS.
Signal Sampling Rate:sample/s.
Data Queue Sequence time: 2 seconds.
In Circuit Resistance:0.001 Ohms.
Operation Current: 7 mA.
Dimensions( L x W x D ): 84 x 50 x 20mm.
Package Included
1 x Watt Meter
1 x User Manual
Power Meter lets you see the power that an appliance is using as well as adding up the energy that the appliance uses over a period of time. You can enter the price that you pay for energy so that the Power Meter shows you how much it has cost to operate the appliance. An internal battery allows the cumulative energy, cumulative cost and settings to be remembered even if there are power outages, so that you don't have to re-enter them.
The appliance that you want to measure is simply plugged in to the socket on the front of the Power Meter and the large, clear display makes it easy for you to see and understand the measurements.
When used with an ELIMINATA Energy Saver, the Power Meter is very useful for 'before and after' measurements, allowing you to identify the savings made.
We are an ISO 9001-2000 certified factory with all our product being CE, EMC, LVD, ETL, ROHS, e-MARK Certfied and we can also provide OEM service. Currently, our products are exported to America, Europe and more and more areas with warm welcome among customers.
Our main products: Power Inverter, Power converter/transformer, solar charge controller and other solar products.
Small order for testing is acceptable.
