Help CenterNew Product: NT-M5 2D USB Wired Handheld Barcode Scanner Support QR, PDF417 and DataMatrix Code
Related Products
-
New Products: NT-1209 2D Bluetooth IP67 Industrial Waterproof Handheld Barcode ScannerUS$ 1 - 95MOQ: 10 Pieces -
NT-2019R QR Code, 1D&2D Handheld Laser Barcode ScannerUS$ 70 - 100MOQ: 50 Pieces
-
High Quality NT-1200 Waterproof QR Code&1D & 2D Laser Handheld Barcode ScannerUS$ 90 - 120MOQ: 50 Pieces
-
NT-8099 High Quality 1D & 2D Handheld Barcode Scanner With Mulitple InterfaceUS$ 110 - 125MOQ: 50 Pieces
-
Hot Sale:NT-8099 High Quality 1D/2D Handheld Barcode ScannerUS$ 110 - 125MOQ: 50 Pieces
Scannning Performance Characteristics | |
Light Source |
indicator light: 528 nm LED;light: 630 nm |
Field of View |
34° V x 46° H |
Scan Angle |
Roll 360°, Pitch ±65°, Yaw ±60° |
Scan Performance | |||
5mil(Code 39): |
9.0-12.0cm |
10mil (PDF417): |
5.0-22.5cm |
13mil(100% UPC/EAN): |
3.0-30.5cm |
10mil(Datamatrix): |
5.2-24.0cm |
Static current20mil(Code 39) |
3.0-42.0cm |
||
Symbology Decode Capability | |
1D |
UPC/EAN with supplementals, Code 39, Code 39 Full ASCII, Trioptic Code 39, RSS variants, UCC/EAN 128, Code 128, Code 128 Full ASCII, Code 93, Codabar (NW1), Interleaved 2 of 5, Discrete 2 of 5, MSI, Codell, IATA, Bookland EAN, Code 32 |
PDF417 |
PDF417, microPDF417 and composite codes |
Postal |
U.S. Postnet and Planet, U.K., Japan, Australian, and Dutch |
2D |
DataMatrix,PDF417, QR Code |
Print Contrast |
>25% |
Interfaces |
RS-232C; USB (Standard, IBM SurePOS, Macintosh) |
Imaging Characteristics | |
Image (Pixels) |
0.35 Megapixel, 752 pixels H x 480 pixels V |
Graphics Format |
Bitmap, Jpeg, Tiff |
Image Transfer Speed |
USB 1.1: Up to 12 Megabits/s ,RS232: Up to 115 kb baud rate |
Image Transfer Time |
Typical USB application is 0.2 seconds with a compressed Jpeg of 100 kb |
Physical Characteristics/User Environment | |
Voltage and Current |
5±10%V DC/ 350 mA |
Operating Temperature |
0° - 50° C |
Storage Temperature |
-40° - 70° C |
Humidity |
5% -95% |
Drop/Shock Specifications |
Withstands 2000g to concrete |
Safety performance |
ROHS, FCC and CE Certificate |
Whole producing chain are with strict quality control, all the goods are inspected before shipment.
CE, CCC, FCC, ROHS, IP67certificates, with high quality guarantee.
