Welding Cable

Name: Welding Cable
Brand: Henan Baofeng
Price: USD $3 - 3 / Meter

FOB Price

USD $3 - $3 / Meter

1000 Meters(Min.Order)

Product Details

Place of Origin:	Henan, China	Brand Name:	Henan Baofeng	Model Number:	Welding Cable
Conductor Material:	Other, Copper CCAM	Insulation Material:	Rubber	Jacket:	Rubber
Number of Conductors:	1, 2, ...	Application:	welding machine,welding tools,, welding generators or other application

Welding Cable

voltage AC 200V~DC 400V
Standards: IEC60245

Welding Cable

Detailed Product Description

1th. Service Conditions

This product is suitable for the welding machine whose voltage to the ground is not more than 200V and pulsating current value is 400V.

2th. Model, Names Main applications and Work In the Temperature

3th. Standards: IEC60245

4th. Specifications, Size, Weight and Technical Data

Model	Name	Main applications	Working temperature of core ≤0C
YH	Natural Rubber Sheath for Welding Cable	Always used indoor	65
YHF	Neoprene Rubber Sheath Welding Cable	Always used outdoor	65
YHF	Synthetic elastomer Sheath Welding Cable	Always used outdoor	65

Conductor Nominal Section (mm2)	Conductive Core	Thickness of Section Sheath (mm)	Average Outer Diameter (mm2)		20oC Conductor Resistance≤(Ω/km)	Reference Weight(kg/km)
Conductor Nominal Section (mm2)	Number/Diameter of Core(mm)	Thickness of Section Sheath (mm)	Min	Max	20oC Conductor Resistance≤(Ω/km)	YH	YHF
10	322/0.20	1.8	7.5	9.7	1.91	146	153.51
16	513/0.20	2.0	9.2	11.5	1.16	218.9	230.44
25	798/0.20	2.0	10.5	13.0	0.758	316.6	331.15
35	1121/0.20	2.0	11.5	14.5	0.536	426	439.87
50	1596/0.20	2.2	13.5	17.0	0.379	592.47	610.55
70	2214/0.20	2.4	15.0	19.5	0.268	790	817.52
95	2997/0.20	2.6	17.0	22.0	0.198	1066.17	1102.97
120	1702/0.30	2.8	19.0	24.0	0.161	1348.25	1392.55
150	2135/0.30	3.0	21.0	27.0	0.129	1678.5	1698.72
185	1443/0.40	3.2	22.0	29.0	0.106	1983.8	2020.74

Henan Baofeng Cable Co., Ltd.: Contact nameGuo; Phone0086-371-86167501; AddressNo. 1202, Floor 12, No. 7, Business Neihuan Road, Zhengdong New Dist.
