Suspension overband magnetic iron separatorManual cleaning tramp iron
No power consumption
Without maintenance
Manufacturer
----Introduce:
Series RCYB suspension overband magnetic iron separator suspends above the conveyor belt or the head pulley and lifts tramp metal from the product burden as it passes through the powerful magnetic field.Cleaning is achieved by manually removing the collected tramp metal from the face of the magnet.
Available in permanent and electromagnetic designs.
Series RCYB suspension overband magnetic iron separator is suitable for removing non-magnetic material on the belt conveyer, vibration conveyer, electric-vibrating feeder and feeder groove.
----Industries:
Wide applications in mining, coal/power generation plant and also in chemical/ food/plastic/ ceramics industries.
----Selection :
Selection this type magnetic separator depends on the feed material, size and feed depth.and also depends on width and speed of your belt conveyor.
----Overall drawing:
----Working picture:
----Specifications:
Model No. |
Belt width |
Suspension height |
Materials Thickness (≤mm) |
Weight (kg) |
Belt speed (≤m/s) |
Overall dimension (mm) |
||
A |
B |
C |
||||||
RCYB-4 |
400 |
125 |
60 |
115 |
4.5 |
400 |
300 |
230 |
RCYB-4-1 |
400 |
75 |
30 |
65 |
400 |
250 |
140 |
|
RCYB-5 |
500 |
150 |
90 |
206 |
500 |
350 |
260 |
|
RCYB-5-1 |
500 |
100 |
50 |
96 |
500 |
260 |
160 |
|
RCYB-6 |
600 |
175 |
120 |
295 |
600 |
450 |
280 |
|
RCYB-6-1 |
600 |
130 |
60 |
158 |
600 |
350 |
180 |
|
RCYB-6.5 |
650 |
200 |
150 |
450 |
650 |
600 |
300 |
|
RCYB-6.5-1 |
650 |
200 |
150 |
450 |
650 |
400 |
300 |
|
RCYB-8 |
800 |
250 |
200 |
680 |
950 |
950 |
380 |
|
RCYB-8-1 |
800 |
200 |
150 |
550 |
800 |
600 |
300 |
|
RCYB-10 |
1000 |
300 |
250 |
1180 |
1100 |
1000 |
380 |
|
RCYB-12 |
1200 |
350 |
300 |
1670 |
1300 |
1340 |
420 |
|
RCYB-14 |
1400 |
400 |
350 |
2350 |
1500 |
1500 |
420 |
|
RCYB-16 |
1600 |
450 |
400 |
2850 |
1750 |
1750 |
460 |
|
