Specifications
suspended electro magnet separatormatch belt width:300-2000mm
iron attracting ability:0.1~35kg
natural cooling
manufacturer
----Introuduce:
Suspended electro magnet separator can be suspend on the steel beam or fixed on shelves.Work with various kinds of conveyor belt, 0.1~35kg ferrous material can be remove from the incompact non-ferrous materials, which is a good choice for improving the quality of material, protecting the equipments in next step.
----Working principle:
Closed aluminium coil with load( exciter)can produce magnetic field. The exciting coil rolled around the iron core to be welded on the undersurface of yoke. Release heat through shell and heat discharge exit.Through motor to drive the conveyor belt running, auto-removing iron realized.
----Structure:
supporting frame, iron cleaning belt, exciter coi, iron core, shell, driving drum, driven drum,motor,reducer,etc.
----Good separation result will be gotten if working with metal detector:
----Overall drawing:
----Technical specifications:
Model |
Belt width |
Suspension height |
Materials Thickness (≤mm) |
Power |
Magnetic (≥mT) |
Motor Power (≤kw) |
Belt speed (≤m/s) |
Weight (kg) |
Overall dimension (mm) |
||||
A |
B |
C |
E |
D |
|||||||||
RCDD-5 |
500 |
150 |
100 |
1.2 |
50 |
1.5 |
4.5 |
1100 |
1800 |
830 |
720 |
750 |
1050 |
RCDD-6 |
600 |
175 |
120 |
1.4 |
60 |
1.5 |
1400 |
2000 |
880 |
810 |
800 |
1150 |
|
RCDD-6.5 |
650 |
200 |
150 |
1.6 |
70 |
2.2 |
1650 |
2100 |
988 |
820 |
888 |
1255 |
|
RCDD-8 |
800 |
250 |
200 |
2.0 |
70 |
2.2 |
2260 |
2300 |
1111 |
860 |
1031 |
1300 |
|
RCDD-10 |
1000 |
300 |
250 |
2.4 |
70 |
3.0 |
3450 |
2600 |
1331 |
880 |
1231 |
1500 |
|
RCDD-12 |
1200 |
350 |
300 |
3.7 |
70 |
4.0 |
4260 |
3000 |
1605 |
950 |
1505 |
1700 |
|
RCDD-14 |
1400 |
400 |
350 |
6.3 |
70 |
4.0 |
5600 |
3300 |
1774 |
1020 |
1674 |
1950 |
|
RCDD-16 |
1600 |
450 |
400 |
6.7 |
75 |
5.5 |
7000 |
3600 |
1974 |
1050 |
1874 |
2400 |
|
RCDD-18 |
1800 |
500 |
450 |
11 |
75 |
5.5 |
8500 |
4380 |
2200 |
1160 |
2100 |
2800 |
|
RCDD-20 |
2000 |
350 |
500 |
13 |
75 |
5.5 |
9600 |
4980 |
2400 |
1190 |
2300 |
3350 |
|
Catalogue: | |
Conveyor belt metal detector |
Self cleaning permanent magnetic separator |
Air cooling self cleaning electromagnetic separator |
Air cooling electromagnetic separator |
Wind cooling self cleaning electromagnetic separator |
Wind cooling electromagnetic separator |
Oil cooling self cleaning electromagnetic separator |
Oil cooling electromagnetic separator |
Manual cleaning permanent magnetic separator |
Electromagnetic vibrate feeder |
Magnetic roller |
Magnetic ferrous traps |
----Our customer:
