JAC Wrecker Truck
- shanghai
- T/T Money Gram
You May Like
Product Details
| Fuel Type | Diesel | Emission Standard | Euro 3 | |
| Condition | New | Transmission Type | Manual | |
| Dimensions (L x W x H) (mm) | 7410*2300*2480mm | Place of Origin | Hubei, China | |
| Brand Name | JAC | Model Number | HFC1061K93 HFC1061 |
Product Description
Specifications
JAC wrecker truck.one slab for two vehicles,
stable, large capacity, easy to drive in narrow alley.
oil saver.
JAC wrecker truck
Entire vehicle | type |
|
|
| |
Overall dimension(mm) | Length | 7410 | 7380 | 7315 | |
Width | 2300 | 2300 | 2300 | ||
Height | 2370/2480 | 2370/2530 | 2200/2365 | ||
Wheelbase | 3800 | ||||
Mass parameter | Max gross weight(kg) | 6400 | 7490 | 6495 | |
Curb weight | 5200 | 5400 | 5430 | ||
Chassis | Engine | Type | CY4102-D3A | CY4102-C3C ISDe140 30 | CY4102-C3D YC4F115-30 |
Power (kw) | 88 | 88/103 | 80/85 | ||
Tire specification | 7.50-16,8.25-16 | 7.50-16,8.25-16 | 7.00-16,7.50-16 | ||
Specialized device | Platform system | Length * width (mm) | 5400*2300 | 5400*2300 | 5400*2300 |
Platform power stroke (mm) | 2680 | 2680 | 2680 | ||
Min. sloping angle (°) | 7.6 | 7.6 | 7.6 | ||
Max lifting capacity (kg) | 3000 | 3000 | 3000 | ||
Winch rated pulling capacity (kg) | 4000 | 4000 | 4000 | ||
Length of steel (meter) | 21 | 21 | 21 | ||
Hoisting system | Max under-hoist effective length (mm) | 1300 | 1300 | 1300 | |
Max lifting capcity (kg) | 1005 | 1005/1895 | 870 | ||
Fully extended max lifting capacity (kg) | 700 | 700/1500 | 600 | ||
Rated pulling capacity (kg) | 6400 | 7400 | 6400 | ||
front picture:
side picture:
detailed picture 1:
detailed picture 2:
If you have any questions about the truck, please feel free to contact me.
Ms. HAN HAN SU Tel: 0086-15172765007
trade manager : truck007
http://truck007.en.china.cn/
