Specifications
Tractor Truck,engine:cummins engine and renault engine.
horse power 340hp and 375hp.
tyre:steel and tubeless trye.
Tractor Truck.
DONG FENG TIAN LONG TRUCK TRACTOR
Tractor model |
DFL4251A9 |
Wheelbase(mm) |
3200+1300 |
Engine |
Model=cummins L375 30 6 cylinders in-line,turbor-charging, inter-cooling,machenical direct injection, inner EGR Max power=276kw@2200rpm, max torque=1480Nm@1400rpm Bore*stroke=114*145mm Displacement = 8900ml Compression ratio=(16.6±0.5)/1 |
Transmission |
Model= 12JS160TA 12 speeds forward with over dirve. one reverse Speed ratio-reverse =11.56 Forward=12.10/9.41/7.31/5.71/4.46/3.48/2.71/2.11/1.64/1.28/1.00/0.78 |
Clutch |
Φ430mm pull-type diaphragm spring clutch, hydraulically operating with air assistance. |
Front axle |
5Tons cast iron |
Rear axle |
13Tons cast iron. Single-stage reduction gear double axle. Main speed ratio=4.11 |
Chassis frame cross section |
300*90*(8+5)mm u-type parallel ladder shape |
Steering |
Hydraulic steering with power assistance |
Leaf spring |
Front =left -3, right-4 semi-elliptic leaf spring |
Fuel tank |
Master fuel tank: 400 liters full steel with cap lock and water separator |
Tyre |
Number =10+1( spare tyre) Specification= 315/80R22.5 or 11.00R20 |
Brakes |
Service brake=duel circuit compressed air brake Parking brake(emergency brake)=energy-saving-spring, compressed air operatiing on double rear axles |
Cabin |
High-roof, two seats, double sleeper Joule heating, cold starting device with electirc heating system. Machenical accelerator pedal and switch, Full-floating cabin, Hydraulic electircal tilt cabin Colorless interlayer windshield Manuel louver, electrical window regulator, central locking . channel type dash board, with air conditoner |
Fifth wheel |
90 |
Approach/departure angle |
18/32 |
wheelbase(mm) |
Front =2039, rear =1860/1860 |
Max speed |
95km/h |
Weight |
Gross weight= 25000kg Curb weight = 8500/8620 Rated traction weight = 39700kg |
Dimension (mm) |
Length*width*height =6810*2500*3600/3700 |
Colour: |
Red/ white |
