Dong Feng Flatbed Tow Truck

Name: Dong Feng Flatbed Tow Truck
Brand: dong feng
Availability: InStock

FOB Price

US$ 19,000 - 23,000 / Unit

1 Unit(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

dong feng flatbed tow truck .
one slab for two vehicles,
stable, large capacity, easy to drive in narrow alley.
oil saver.

dong feng flatbed tow truck

Entire vehicle	type
	Overall dimension(mm)	Length	7410	7380	7315
		Width	2300	2300	2300
		Height	2370/2480	2370/2530	2200/2365
		Wheelbase	3800
	Mass parameter	Max gross weight(kg)	6400	7490	6495
	Mass parameter	Curb weight	5200	5400	5430
Chassis	Engine	Type	CY4102-D3A	CY4102-C3C ISDe140 30	CY4102-C3D YC4F115-30
	Engine	Power (kw)	88	88/103	80/85
	Tire specification		7.50-16,8.25-16	7.50-16,8.25-16	7.00-16,7.50-16
Specialized device	Platform system	Length * width (mm)	5400*2300	5400*2300	5400*2300
		Platform power stroke (mm)	2680	2680	2680
		Min. sloping angle (°)	7.6	7.6	7.6
		Max lifting capacity (kg)	3000	3000	3000
		Winch rated pulling capacity (kg)	4000	4000	4000
		Length of steel (meter)	21	21	21
	Hoisting system	Max under-hoist effective length (mm)	1300	1300	1300
		Max lifting capcity (kg)	1005	1005/1895	870
		Fully extended max lifting capacity (kg)	700	700/1500	600
		Rated pulling capacity (kg)	6400	7400	6400

front picture:

side picture

detailed picture 1:

detailed picture 2:

If you have any questions about the truck, please feel free to contact me.
