Help CenterOem 10/100/1000M Media Converter Fiber Optic Equipment
Related Products
-
a Pair BIDI WDM Single Fiber , 20km Ethernet Fiber Media ConverterNegotiableMOQ: 10 Pairs -
Oem Factory Single Fiber Fast Ethernet Media Converter PCBAUS$ 1 - 20MOQ: 1 Piece
-
Oem Factory Single Mode Fiber Media Converter PCBAUS$ 1 - 20MOQ: 1 Piece
-
Oem Factory 1sc 1rj45 Ethernet Fiber Media Converter PCBAUS$ 1 - 20MOQ: 1 Piece
-
Oem Factory 10100m Optical Fiber Media Converter PCBAUS$ 1 - 20MOQ: 1 Piece
a pair BIDI WDM single fiber , 20km ethernet fiber media converter
Product Description
Media converters can be used anywhere in the network to integrate newer technology with existing equipment to support new applications, technologies and future growth. Instead of costly, across-the-board upgrades, media converters can extend the productive life of the existing cabling as well as the active equipment.
POWERLINK supply 10/100Base Ethernet Fiber Media Converters, 1000Base Gigabit Fiber Media Converter,SFP Fiber Media Converter, Options in singlemode dual fiber, multimode dual fiber and singlemode single fiber. We also supply Media Coverter Chassis, like 14 slot media converter chassis and 16 slot media converter chassis, used to manage the various media converters.
Features
- AutoCross™: Automatically detects and configures the twisted pair port on the converter to the correct MDI or MDI-X configuration.
- Link Pass Through: Link Pass Through is a troubleshooting feature that allows the media converter to monitor both the fiber and copper RX ports for loss of signal.
- Automatic Link Restoration: The medio converters will automatically re-establish link in all network conditions.
Selectable speed setting: The converter can be set to 10Mbps or 100Mbps. Both copper and fiber ports are automatically set to the same speed. Devices connect to duplex mode of link partner.
Key Features
- 10/100Mbps auto-negotiation
- Supports IEEE 802.3x full-duplex flow control and back pressure half-duplex flow control
Supports self-learning - Standards: IEEE802.3, IEEE802.3u, IEEE802.3x, 10/100Base-TX, 100Base-FX, 10/100/1000Base-TX, 1000Base-FX/LX
LED status of Link, activity, Full/half duplex, speed and power on diagnostic function - Extremely low power consumption and low heat
- Reliable and stable performance
Specification
| Parameter | Specification | ||||
| UTP Port | 1-port RJ45 | 2-port RJ45 | 4-port RJ45 | 6-port RJ45 | 8-port RJ45 |
| Power Supply | External or built-in | External | External | External | External |
| Dimension (L×W×H) (mm) | 26x70x95 (with external power) | 26*70*95 (with external power) | 30*110*140 (with external power) | 30*110*140 (with external power) | 30x110x140 (with external power) |
| UTP Rate | 10/100Mbps | ||||
| Fiber Port | Simplex SC, ST, FC available | ||||
| Fiber Rate | 100Mbps | ||||
| Fiber Wavelength | 1310/1550nm | ||||
| Fiber Mode | Single-mode | ||||
| Distance | 20km | ||||
| LED Indicator | TX LINK, FX LINK, TX ACT, FX ACT, PWR, FDX. | ||||
| Working Temperature | -20~75°C | ||||
| Relative Humidity | 5%~90% | ||||
Applications:
- Extend Ethernet Network Distances
- It use the 10/100BASE-T to 10BASE-FL speed setting (back-to-back) to extend the distance between two 10/100BASE-T devices up to 100km. using single mode fiber without a repeater.
- Extend Fast Ethernet Network Distances
It use the 100/1000BASE-TX to 100/1000BASE-FX setting to extend the distance between any two 100/1000BASE-TX devices up to 100km. using single mode fiber. Or interface directly with a 100/1000BASE-FX compliant port on any device to provide a 100/1000 BASE-TX port interface.
- Packaging : bags&caron box
- Shipping: International Express: Fedex, DHL, UPS, TNT and EMS.If you have another preferred carrier, please notify us in advance.
- FedEx Overnight: It will take 1-3 business days (weekends and holidays excepted) for delivery.
- DHL: It will take 2-4 business days (weekends and holidays excepted) for delivery. For Spain, Italy, Brazil and some other countries, items will take longer time to arrive due to customs clearance period.
- "One to one" heart to heart service:Sales representative serve for five clients only. We look forward the continuing long-term services for you, but not just one or two times' co-operation.
- Perfect after-sales service :24-hour designated telephone number, e-mail and customer manager
Shenzhen powerlink electronic technology company limited is a high-tech private-run enterprise specialized in research development ,manufacturing customized video and fiber optical media converter products and power supply products . mainly manufacture Optical Fiber Transmission, Data Communication and Network Access Equipments. Included LD/PD, Optical Fiber Communication ,fiber media converter, digital video converters, media converters,Digital CCD cameral ,ethernet switch, video converter, fiber optic modem, protocol converter, fiber optic adapter, fiber optic cable, patch cord, optical coupler, wavelength division multiplexer, optical attenuator, fiber optic splice enclosure, fiber optic terminating box ,LED power supply ,switch power supply etc, which have been are widely applied in many industries like telecom, broadcast&television, finance,traffic safety protection, computer, campus network, interliligent district and electronic government affairs engineering etc. those products are used widely in more than 30 industries , such as Telecom ,safe city Surveillance, International Airports, Highway, Power, Hydropower, Public Security.
Why POWERLINK
- Higher quality but lower price :Business Process Outsourcing. Outsourcing the repetitive non-core or core production process to professional suppliers, reduce cost; improve service at the same time. Can concentrate on control of the company's core technology, achieve high-end products positioning as well as understand the whole industry chain deeply
- Complete solution, meet individual requirements
- We thoughtfully consider from the initial design to material and supplier selection, from the main parts to one wire or even a screw. Combination local geographical, climatic characteristics, as well as factors such as regional culture in of product design, and fully customized to meet the requirements.
- Resource integration, provide you with the most satisfied products :We have accumulated thousands of solar manufacturers, hundreds of friendly cooperator, we will continue the accumulation.
- Professional technique, quality assurance:Control the quality from the source, professional product engineers and sales engineers make checks at all levels.
- ERP management :All management runs through pre-sale, sales, after- sale strictly in accordance with the ERP.
- Standardization,Atumization,Vitrification,Definite Responsibility,More Optimized Flow
Factory Image:
