150kg 200kg Single Shear Beam Load Cell
US$ 15 - 20
MOQ: 10 Sets
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
CZS
Model Number:
CZS646B
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
60kg 100kg Single Shear Beam Load CellUS$ 10 - 12MOQ: 10 Sets -
10kg 15kg Single Shear Beam Load CellUS$ 10 - 12MOQ: 10 Sets
-
Parallel Beam Load Cell Weighing Scales With Capacity 3 to 60kg Load CellsUS$ 3 - 4MOQ: 1 Piece
-
Aluminum Single Point Load Cell 30KG 150KG for Platform ScaleUS$ 5 - 6MOQ: 1 Piece
-
0.3kg 1kg 2kg 3kg Small Capacity With Precision Load CellsUS$ 5 - 6MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
CZS
Model Number
CZS646B
Single Point Shear Beam weighing scales aluminum Load Cells
Rated load (kg): 100,150,200,300,500
Main features:
Alloy aluminum.
It is hermetically sealed with glue to IP65, surface anodized and anti-corrosion,
integral structure and easy installation.
Suit for electronic top scale, floor scale and other weighing equipment
Size:200x50x40mm
Recommended Platform Size:400X400MM
| Precision | C2/C3 |
| Zero balance(%F.S) | ±1.0%FS |
| Rated output(mv/v) | 2.0±0.1mV/V |
| Creep(%F.S/30min) | ±0.02/±0.017 |
| Excitation voltage(V) | 9~12(DC) |
| Input resistance(Ω) | 405±10Ω |
| Output resistance(Ω) | 350±3Ω |
| Ultimate overload (%F.S) | 150% |
| Insulation resistance(MΩ) | ≥5000(100VDC) |
| Temp. effect on span(%F.S/10℃) | ±0.02/±0.014 |
| Comprehensive error(%F.S) | 0.02±%FS |
| Temp. effect on zero(%F.S/10℃) | ±0.03/±0.017 |
| Use temp. range(℃ ) | -10~+40 |
| Creep(%F.S/30min) | ±0.02/±0.017 |
| Safe overload (%F.S) | 120% |
| Defend grade | IP65 |
Dimension Size:
