BHPRO A K Q Span Used Roll Forming Machine

BHPRO A K Q Span Used Roll Forming Machine thumbnail-1
BHPRO A K Q Span Used Roll Forming Machine thumbnail-2
BHPRO A K Q Span Used Roll Forming Machine thumbnail-3
BHPRO A K Q Span Used Roll Forming Machine thumbnail-4
BHPRO A K Q Span Used Roll Forming Machine thumbnail-5
BHPRO A K Q Span Used Roll Forming Machine thumbnail-6
BHPRO A K Q Span Used Roll Forming Machine photo-1
BHPRO A K Q Span Used Roll Forming Machine photo-2
BHPRO A K Q Span Used Roll Forming Machine photo-3
BHPRO A K Q Span Used Roll Forming Machine photo-4
BHPRO A K Q Span Used Roll Forming Machine photo-5
BHPRO A K Q Span Used Roll Forming Machine photo-6
US$ 28,000 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Arching Machine
Tile Type:
Colored Glaze Steel
Use:
Roof
Contact Supplier Request Quote Chat Now
Yingkou Professional Roll Forming Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Arching Machine
Tile Type Colored Glaze Steel
Use Roof
Production Capacity 10-15m/min
Place of Origin Liaoning, China
Brand Name pro
Model Number pro-1000-680
Power(W) 7.5kw+3.0kw
Voltage 380V 50Hz 3phases
Dimension(L*W*H) 8900mm*2230mm*2300mm
Weight 12T
Certification CE ISO
Warranty 2 Years
After-sales Service Provided Engineers available to service machinery overseas
Product Description
Size:
8900mm×2230mm×2300mm
Total weight:
About 12 ton
Material of cutter:
Cr12 moV
Material of rollers:
#45 steel, quenched, hard chrome plated
Material of roller shafts:
45# steel, galvanized
Main Motor Power:
18.9KW
Forming power: 7.5KW
 Bending power: 3.0KW+1.1x2 KW
Cutting power: 4.0KW
Seaming power: 1.1 KW+1.1KW
Working Speed:
Straight sheet: 15m/min
Arch sheet: 13m/min
Seaming: 16m/min
Step of rollers: 13+1
Thickness of the coil:
0.6-1.5mm
Feeding Width:
1000mm
Effective Width:
680mm
Depth of the groove:
223 mm
Utilization ratio:
 68%
Largest span:
 38m
Detailed Images




                                 Drawing profile :


Packing & Delivery

Payment terms:T/T. 30% T/T in advance,70% before shipment.

Delivery time:within 7 days after receiving 30% down payment

Guarantee period: 13 months after B/L date.

Certification: CE.

Packing: Nude-packing, 40"HQ x 1 for shipment
