Handheld Infrared Thermometers UNI-T UT302A Industrial Temperature Gauge Non-contract Digital IR Thermometer Gun -32 - 450
US$ 35 - 50
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT302A
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UNI-T UTi160B Portable Infrared Thermal Imager Imaging Clearly Industry 3.5 TFT Screen CameraNegotiableMOQ: 1 Piece -
Portable Infrared Thermal Imager UNI-T UTi160B Imaging Clearly Industry Temperature MeterNegotiableMOQ: 1 Piece
-
Best AZ8866 Non-contact Digital Infrared Thermometer IR Thermometer Temperature With -20~420 DegreeNegotiableMOQ: 1 Piece
-
AZ8868 Infrared AZ-8868 Thermometer,8868 Gun Type IR ThermometerNegotiableMOQ: 1 Piece
-
AZ8859 Non Contact Infrared Thermometer Gun Type IR Thermometer Digital Infrared Thermometer -20~420 DegreeNegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT302A
Usage
Industrial
Theory
Infrared Thermometer
Accuracy
±1.8°C or ±1.8%
Temperature Range
-32 - 450°C
Handheld Infrared Thermometers UNI-T UT302A Industrial temperature gauge Non-contract Digital IR Thermometer Gun -32 - 450
Detailed
UT302 series infrared thermometer, by measuring the infrared energy radiated by the target surface to determine the surface temperature, the temperature measurement of professional diagnostic tools.This product has a different measurement temperature range, each divided into A, B, C, D four models.
Applicable to electrical instrumentation equipment, engines, electric motors, industrial production and HVAC air conditioning system for easy detection, security, fast find hidden faults
Contrast
| Specifications | Range | |||
| Model | UT302A | UT302B | UT302C | UT302D |
| Temperature Range | -32 - 450°C | -32 - 550°C | -32 - 650°C | -32 - 1050°C |
| -26 - 842°F | -26 - 1022°F | -26 - 1202°F | -26 - 1922°F | |
| Accuracy | ±1.8°C or ±1.8% | ±1.8°C or ±1.8% | ±1.8°C or ±1.8% | ±1.8°C or ±1.8% |
| Repeatability | ±0.5°C or ±0.5% | ±0.5°C or ±0.5% | ±0.5°C or ±0.5% | ±0.5°C or ±0.5% |
| Resolution | 0.1°C/0.1°F | 0.1°C/0.1°F | 0.1°C/0.1°F | 0.1°C/0.1°F |
| Distance to Spot Size | 20:1 | 20:1 | 20:1 | 20:1 |
| Response Time | 250mS(95% of reading) | 250mS(95% of reading) | 250mS(95% of reading) | 250mS(95% of reading) |
| Emissivity | 0.10-1.0 Adjustable | 0.10-1.0 Adjustable | 0.10-1.0 Adjustable | 0.10-1.0 Adjustable |
| Laser Type | Class 2 | Class 2 | Class 2 | Class 2 |
| Laser Power | <1mW | <1mW | <1mW | <1mW |
| Laser Wavelength | 630nm - 670nm | 630nm - 670nm | 630nm - 670nm | 630nm - 670nm |
| Spectral Response | 8μm -14μm | 8μm -14μm | 8μm -14μm | 8μm -14μm |
| Features | ||||
| °C/°F Selection | √ | √ | √ | √ |
| Laser Switch | √ | √ | √ | √ |
| Display Hold( s) | 8 Seconds | 8 Seconds | 8 Seconds | 8 Seconds |
| Data Hold | √ | √ | √ | √ |
| Auto Power Off | √ | √ | √ | √ |
| Low Battery Indication | √ | √ | √ | √ |
| MAX Mode | √ | √ | √ | √ |
| MIN Mode | √ | √ | √ | √ |
| DIFF Mode | √ | √ | √ | √ |
| AVG Mode | √ | √ | √ | √ |
| LCD Backlight | √ | √ | √ | √ |
| Electricity Cut-off Memory | √ | √ | √ | √ |
| Tripod Mount | √ | √ | √ | √ |
| General Characteristic | ||||
| Power | 9V Battery(6F22) | |||
| LCD Size | 32mm X 29mm | |||
| Product Color | Red and Grey | |||
| Product Net Weight | 322g | |||
| Product Size | 169mm X 138mm X 53mm | |||
| Standard Accessories | Battery, Carrying Bag, USB Cable (External Power) | |||
| Standard Individual Packing | Blister, English Manual | |||
| Standard Quantity Per Carton | 20 PCs | |||
| Standard Carton Measurement | 628mm X 345mm X 468mm (0.101 CBM Per Standard Carton) | |||
| Standard Carton Gross Weight | 13 Kg | |||
Fitting
1. Battery(not included)
2. Carrying Bag,
3. USB Cable (External Power)
