UNI-T UTi160B Portable Infrared Thermal Imager Imaging Clearly Industry 3.5 TFT Screen Camera
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UTi160B
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Portable Infrared Thermal Imager UNI-T UTi160B Imaging Clearly Industry Temperature MeterNegotiableMOQ: 1 Piece -
Best AZ8866 Non-contact Digital Infrared Thermometer IR Thermometer Temperature With -20~420 DegreeNegotiableMOQ: 1 Piece
-
AZ8868 Infrared AZ-8868 Thermometer,8868 Gun Type IR ThermometerNegotiableMOQ: 1 Piece
-
AZ8859 Non Contact Infrared Thermometer Gun Type IR Thermometer Digital Infrared Thermometer -20~420 DegreeNegotiableMOQ: 1 Piece
-
AZ8838 Infrared Food Thermometer Infrared Temperature Measuring Range:-40C ~ +280 C Probe:-40C ~ +200 CNegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UTi160B
Usage
Industrial
Theory
Temperature Sensor
Accuracy
±2°C
Temperature Range
-20~300
UNI-T UTi160B Portable Infrared Thermal Imager Imaging Clearly Industry 3.5 TFT Screen Camera
Introduction
UTi160B (160*120): Point-and-Detect, Imaging Clearly: “Direct to Target” design permits simultaneous view on image and temperature data during aiming at objects. It delivers clear and crisp images without missing instant details or defects such as frame drop or trailing so as to find out all problems.
Applicable industries: electric power,construction,electronics,smelting,energy,railway,automobile,petrochemical.
Specification
| Specifications | ||
| Model | UTi160B | UTi160D |
| Sensor Type | Uncooled Focal Plane Arrays | |
| Resolution | 160 * 120 | 160 * 120 |
| View of View / Minimum Focus Distance | 20*15/0.1m | 20*15/0.1m |
| Spatial Resolution (IFOV) | 2.2mrad | |
| Visible Light Resolution | no | 640*480 full color |
| Image Mode | Infrared | Infrared/visible light/pip/blend |
| Focus | Manual | |
| Infrared Spectral Band | 8~14um | |
| NETD | ≤0.08℃ 30℃ | ≤0.08℃ 30℃ |
| Temperature Range | -20℃-300℃ | -20℃-400℃ |
| Accuracy | ±2°C or ±2% (whichever is greater) | |
| Features | ||
| Display Type | 3.5"TFT LCD; Ratable | |
| Palettes | Iron, Iron-Invert, Rainbow, Feather, Grey, Grey Inverted | |
| Images Adjustable | Auto/Manual | |
| Image Format | *·TIR | *·TIR .CCD(visible light) |
| Video Output | Support: PAL(50Hz) or NTSC(60Hz) | |
| Measurement Mode | Movable Spot, Area(MAX,MIN) | 4Movable Spot, Area(MAX,MIN),isothermality analysis |
| Parameters Setting | Emissivity, Distance, Temperature, Relative Humidity | |
| Temperature calculate | √ | √ |
| High/Low Temperature Alarm | √ | √ |
| Laser Pointer | √ | √ |
| Image Capture | √ | √ |
| Image Storage | 2GB SD Card | |
| Temperature Units | ℃/℉ | |
| Flashlight | no | yes |
| Support Languages | English/Simplified Chinese | |
| Factory Setting | √ | |
| Power Mode | Standard / Power Saving auto power off | |
| Analyzing Software | Report format:can automatic create report,can transmit to word format | |
| Water Proof Rating | IP54 | |
| Impact/Vibration | 25G/2G | |
| General Characteristics | ||
| Power | Li-ion 1450mAh | |
| Product Color | Red and Gray | |
| Product Net Weight | UTi160B/D-600g(battery included); UTi380D-700g(battery included UTi380D) | |
| Product Size | 220mm * 215mm * 80mm | |
| Standard Accessories | Batteries, Seat Charger, SD Card (2G), Card Reader,Video Cable Camera Cover, Lens hood,Software CD | |
| Standard Individual Packaging | Gift box, Toolbox, User Manual | |
| Standard Quantity Per Carton | 3PCs | |
| Standard Carton Measurement | 510mm*375mm*320mm | |
| Standard Carton Gross Weight | 11.5 Kg | |
| Optional Accessories* | ||
| Power Adapter,16G SD card,Vehicular Power Cord, 3.8 6.4 12 38 Lens | ||
Accessory
1. Batteries, (not included)
2. Seat Charger,
3. SD Card (2G),
4. Card Reader,
5. Video Cable Camera Cover,
6. Lens hood,
7. Software CD,
8. Power Adapter*,
9. 16G SD card*,
10. Vehicular Power Cord*,
11. 3.8 6.4 12 38 Lens*
