Hydraulic Drilling Rig:
Awarded ISO9001 SON COC ECTN Blasting Rock Crawler Hydraulic Drilling Rig
1, Technical Parameter
Model HS100
Rock hardness F=6-20
Hole diameter(mm) 80-105
Hole depth(m) 25
Working pressure(mpa) 1.0-2.4
Air consumption(M3/min) ≥10
Power head Rotary Speed (forward / reverse)rpm 0-65
Lifting force (KN) 15
Drill Rod Standard (mm) 60*2000
Climbing Ability Blasting drill of the deep drilling rigs
Grade Clearance ((mm) 254
Walking speed (Km/h) 2.0
Drilling boom Rising angles -
Drilling boom angular -
Mast Sliding angular -11.5°~+36.5°
Mast Sliding pitch -118.5°~+23.5°
Mast Sliding Compensating (mm) 900
Dimension (mm) 4100*2030*2020
Total Weight (kg) 3100
2, Appliance Range
a, Mining (Bore hole for blasting)
b, Quarry ( cement mill usage)
c: Transportation
d, Constructure
e, Water conservancy project'
f, Electricity
3, The machine feature
(1), Powerful driving force: Select four cylinders diesel engine. Diesel engine prefilter, oil filter, peper filter, three steps filter terms let diesel engine obtain long life.
(2), Strength propel and rotary system: Adopt big torque hydraulic motor driven rotary system, the rotary system are offering powerful torque storage, decrease the rate of sticking of tool.
(3), New type arm of drilling rig: round drill boom, jib lubbing mechanism,easy to adjust.
(4), Big hydrulic motor power driven, let drilling rig easy to climb.
3, Our Company Brief Introduction
Chongqing Hi-sea Marine Equipment Import & Export Co., Ltd is in mining machinery field and marine field since 1996 year. We are professional manufacturer and supplier of air compressor, hydraulic crawler mining rotary bore hole drilling rig, mining machinery parts, Marine Deck Equipment, Marine Electric Equipment, Marine Outfitting Equipment etc. We can provide the project solutions, including design, manufacture and export large, medium and small ship according to the requirement. We have our own casting and machinery factory in Chongqing. Superior quality, efficiency and professional service is our business principles, we stick to ISO9001-2000, ISO9001:2008, ISO14001:2004 and rules of international society classifications. quality control.
4, Why do you choose the truck mounted hydraulic drilling rig?
1), We are professional supplier of drilling rig.
Our company has exported mining equipment since 1996 years. There are abundant experience in this field.
2), Good Quality.
Quality is the life of the company. We can provide ISO9001:2000, ISO9001:2008, ISO14001, ECTN, SONCAP, COC, ABS, KR, NK, GL, LR, RINA, CCS, IRS, DNV classification society certificate for many products.
3), We have own factory.
The competitive price can be promised. Various type drilling rig can be selected.
4), 100% spare parts can be supplied.
We can supply all spare parts: rubber hose, drill bit, drill rod, DTH hammer, motor, engine parts etc.
5), Superior Service
Patient, responsible, active service attitude. Online, Phone, Mail are all available.
6), We will recommend a suitable type for you and send you a best quotation.
A, How diameter hole do you need to drill?
B, How depth do you need to drill?
C, How many Ton rock do you need to drill every hour?
D, What Type of Power do you need, diesel engine drive or motor drive?
E What is the Power supply ( KW, HP)?
Various Portable Crawler Hydraulic Drilling Rig (For Cement Mill) Specification
Model |
Dia. Of hole |
Depth of hole |
Push length |
Working pressure |
Air comsumption |
Max lifting capacity |
Remark |
HS140 |
105-140 |
≥30 |
3 |
1.0-2.4 |
22 |
25 |
High Pressure Crawler Drill |
HS120 |
105-120 |
≥30 |
3 |
0.7-1.4 |
21 |
20 |
Mdeium Pressure Crawler Drill |
HS100 |
80-105 |
≥25 |
2 |
0.7-1.0 |
13 |
15 |
Low Pressure Crawler Drill |
HS120 |
80-115 |
≥25 |
3 |
0.7-1.4 |
13 |
20 |
Low(Mdeium)Pressure Crawler Drill |
HS140 |
105-140 |
≥25 |
3 |
1.0-2.4 |
15 |
20 |
High(Mdeium)Pressure Crawler Drill |
HS10 |
115-254 |
120 |
3 |
1.05-2.46 |
16-30 |
70 |
WATER DRILL |
HS8S |
105-125 |
≥25 |
3 |
1.0-2.4 |
15-21 |
20 |
High Pressure Crawler Drill |
HS100J |
80-105 |
≥25 |
2 |
0.7-1.0 |
≥10 |
15 |
Low Pressure Crawler Drill |
HS130 |
105-140 |
≥25 |
3 |
1.0-2.4 |
≥15 |
18 |
High Pressure Crawler Drill |
HS125 |
80-115 |
≥25 |
3 |
0.7-1.4 |
≥13 |
17 |
Low(Mdeium)Pressure Crawler Drill |
HS11S |
105-125 |
18 |
3000 |
1.7 |
18 |
32 |
all-in-one |
HS910A |
80-105 |
25 |
2 |
0.7-1.0 |
9-13 |
15 |
|
HS910B |
80-105 |
25 |
2 |
0.7-1.0 |
9-13 |
15 |
|
HS920A |
80-125 |
25 |
3 |
1.0-1.7 |
9-16 |
15 |
|
HS920B |
80-125 |
25 |
3 |
1.0-1.7 |
9-16 |
15 |
|
HS930A |
80-125 |
25 |
3 |
1.0-2.4 |
9-16 |
17 |
|
HS940A |
105-165 |
25 |
|
1.0-2.4 |
10-18 |
22 |
Crawler Borehole Hydraulic Drilling Rig Drawing
Crawler Horizontal and Vertical Portable Hydraulic Drilling Rig Working in Quarry
Crawler Rock Blasting High Effiency Hydraulic Drilling Rig
