Specifications
Mining Depth Measure Equipment:1. Max minitor depth 1000 m
2. USB connect
3. True and exact figure
4. Reasonable Price
Mining Depth Measure Equipment:
Underground Coal Mining Depth Measure Equipment
Brief Introduction:
The automatic measure equipment full hydraulic drilling rig drilling depth is widely using in mining.
The mining depth measure equipment can get true and exact information of the hole depth, angle, position. It is automatic measure.
Feature:
1. Saving cost, if there are no depth monitor device, it will increase the managing cost.
2. Safety, to get the true and exact information benefits gas drainage.
3. Available for management, each hole record can be display including depth, angle, position, staff number, drilling hole time, drilling hole efficiency.
Main Specification:
Max. Monitor Depth |
1000 Meters |
Measurement Error |
< 1% |
Working Voltage |
660V/36VAC |
Voltage Fluctuation Application Scope |
±20% |
Max. Storage Data Volume |
500 Items |
Memory and Computer Communication Mode |
USB Communication |
Drill Hole Depth Monitor Equipment Picture:
Drilling Rig Operation Platform, No. 2 Sensor and No. 3 Sensor (loaded in drilling rig operation platform), Explosion Proof Type Electromagnetive Valve, Depth Monitor Device Power Source Box and Power Control Box, No.1 Sensor (loaded in drilling rig track equipment).
