Home > Instruments & Meters > Meter for Liquid & Gas > Thermometer & Hygrometer > HT02 Sell Hot Thermograph Camera Infrared Thermal Camera HT-02 Digital Infrared Imager
HT02 Sell Hot Thermograph Camera Infrared Thermal Camera HT-02 Digital Infrared Imager
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OEM
Model Number:
HT-02
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UNI-T UT303D Handheld Gun Digital Lase IR Infrared Thermometer -32C-1250C Temperature GunNegotiableMOQ: 1 Piece -
-32C-1050C UNI-T UT303C Professional Non-Contact Infrared IR Laser LCD Digital ThermometerUS$ 50 - 130MOQ: 1 Piece
-
High Temperature Infrared Thermometer AS872D -50~1150C(-58-2102F) Non Contact Digital IR Gun Infrared ThermometerNegotiableMOQ: 1 Piece
-
Handheld Infrared Thermometer AR872+ Temperature Range -18 C~1350 C High Temperature Infrared ThermometerNegotiableMOQ: 1 Piece
-
Smart Sensor Infrared Thermometer AR862A+ Measurement Range: -50 to 850'CNegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
OEM
Model Number
HT-02
Usage
Industrial
Theory
Other, Infrared Thermal Imager
Accuracy
±2°C or 2% readings
Temperature Range
-20-300
HT02 Sell Hot Thermograph Camera Infrared Thermal Camera HT-02 Digital Infrared Imager
Introduction
HT-02 is a thermal Imaging Camera which combines the functions of surface temperture measurement and real-time thermal Imaging.
To improve recognition,this product is equipped with a vision camera.Based on pratical requirements,it can turn thermal image into visional image.Thermal image into visional image. Thermal Image and visional image can be stored them in PC which are used to generate report or for printing.HT-02 is easy to operate.After seconds it can be tested. This product is the potimum product for elecrician and maintaineer. It can quickly find out the problem area.
The following functions help to improve the accuracy and usability of product:
1. Adjustable radiation coefficient and reflection background compensation help to improve the accurancy of the measurement of semi-reflective surface.
2. The marking of hot spot and cold spot can help user to locate the hottest and coldest area of thermal imaging temperature.
3. Options of color palette
Performance Indexes
Display: 2.8 inch color display
Resolution: 60*60
Total pixel: 3600
FOV/Shortest focal length: 20× 20/0.5m
Thermal sensitivity :0.15
Measuring mode: Infrared focal plane measuring temperature
Temperature range: -20 -300 (-4 -572 )
Measuring accuracy: ±2
Wavelength range: 8-14μm
Image frequency: 8HZ
Emissivity: 0.1-1.0/Adjustable
Focus mode: Fixed
Palette: Iron color,rainbow,black and white
Image storage: SD card(32G)
File format: JPG
Set control: Unit Adjustment/Language/Date Time Format/automatic shut down
Battery type: 3.7V rechargeable lithium battery
Adapter voltage: DV 5V output
Operating temperature: 0 -50
Storage temperature: -40 -70
Humidity: <90%RH
Vibration: 2G, IEC60068-2-6
Drop resistance: 2m
Size: 230×80×52mm
Net Weight: 410g
