UNI-T UT303D Handheld Gun Digital Lase IR Infrared Thermometer -32C-1250C Temperature Gun
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT303D
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
-32C-1050C UNI-T UT303C Professional Non-Contact Infrared IR Laser LCD Digital ThermometerUS$ 50 - 130MOQ: 1 Piece -
High Temperature Infrared Thermometer AS872D -50~1150C(-58-2102F) Non Contact Digital IR Gun Infrared ThermometerNegotiableMOQ: 1 Piece
-
Handheld Infrared Thermometer AR872+ Temperature Range -18 C~1350 C High Temperature Infrared ThermometerNegotiableMOQ: 1 Piece
-
Smart Sensor Infrared Thermometer AR862A+ Measurement Range: -50 to 850'CNegotiableMOQ: 1 Piece
-
LDC IR Display Digital Infrared Thermometer AR320 -32~320C(-26~608F) Non-Contact IR Laser Point Gun PyrometerNegotiableMOQ: 5 Pieces
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT303D
Usage
Industrial
Theory
Infrared Thermometer
Accuracy
±1.8°C or ±1.8%
Temperature Range
-32°C-1250°C
UNI-T UT303D Handheld Gun Digital Lase IR Infrared Thermometer -32C-1250C Temperature Gun
Detailed
UT303 series infrared thermometer, by measuring the infrared energy radiated by the target surface to determine the surface temperature, the temperature measurement of professional diagnostic tools. This product has a different measurement temperature range, it was divided into: A, B, C, D four models.
Suitable for the process of electrical instrumentation equipment, engines, air conditioning systems and HVAC control, inspection iron and steel, glass, plastic, cement production process temperature.
Applied Railway: Train traveling axis probe temperature, identify problems and in handling to prevent train accidents on the way to travel.
Contrast
| Specifications | Range | |||
| Model | UT303A | UT303B | UT303C | UT303D |
| Temperature Range | -32°C- 650°C | -32°C-850°C | -32°C-1050°C | -32°C-1250°C |
| -26°F-1202°F | -26°F-1562°F | -26°F-1922°F | -26°F-2282°F | |
| Accuracy | ±1.8°C or ±1.8% | ±1.8°C or ±1.8% | ±1.8°C or ±1.8% | ±1.8°C or ±1.8% |
| Repeatability | ±0.5°C or ±0.5% | ±0.5°C or ±0.5% | ±0.5°C or ±0.5% | ±0.5°C or ±0.5% |
| Resolution | 0.1°C/0.1°F | 0.1°C/0.1°F | 0.1°C/0.1°F | 0.1°C/0.1°F |
| Distance to Spot Size | 30:1 | 30:1 | 30:1 | 30:1 |
| Response Time | 250mS(95% of reading) | 250mS(95% of reading) | 250mS(95% of reading) | 250mS(95% of reading) |
| Emissivity | 0.10-1.0 Adjustable | 0.10-1.0 Adjustable | 0.10-1.0 Adjustable | 0.10-1.0 Adjustable |
| Laser Type | Class 2 | Class 2 | Class 2 | Class 2 |
| Laser Power | <1mW | <1mW | <1mW | <1mW |
| Laser Wavelength | 630nm- 670nm | 630nm- 670nm | 630nm- 670nm | 630nm- 670nm |
| Spectral Response | 8μm-14μm | 8μm-14μm | 8μm-14μm | 8μm-14μm |
| Features | ||||
| °C/°F Selection | √ | √ | √ | √ |
| Laser Switch | √ | √ | √ | √ |
| Display Hold | 8 Seconds | 8 Seconds | 8 Seconds | 8 Seconds |
| Data Hold | √ | √ | √ | √ |
| Auto Power Off | √ | √ | √ | √ |
| Low Battery Indication | √ | √ | √ | √ |
| MAX Mode | √ | √ | √ | √ |
| MIN Mode | √ | √ | √ | √ |
| DIFF Mode | √ | √ | √ | √ |
| AVG Mode | √ | √ | √ | √ |
| LCD Backlight | √ | √ | √ | √ |
| Electricity Cut-off Memory | √ | √ | √ | √ |
| Tripod Mount | √ | √ | √ | √ |
| General Characteristic | ||||
| Power | 9V Battery(6F22) or USB | |||
| LCD Size | 32mm X 29mm | |||
| Product Color | Red and Grey | |||
| Product Net Weight | 322g | |||
| Product Size | 169mm X 138mm X 53mm | |||
| Standard Accessories | Battery, Carrying Bag, USB Cable (External Power) | |||
| Standard Individual Packing | Blister, English Manual | |||
| Standard Quantity Per Carton | 20 PCs | |||
| Standard Carton Measurement | 628mm X 345mm X 468mm (0.101 CBM Per Standard Carton) | |||
| Standard Carton Gross Weight | 13Kg | |||
Fitting
1. Battery(not included)
2. Carrying Bag,
3. USB Cable (External Power)
