Graphic Power Quality Analyzer AFLEX-6300

US$ 580 - 620 MOQ: 1 Piece

Key Specifications

Brand Name:

TES

Model Number:

AFLEX-6300

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ShenZhen

Delivery Detail:

Delivery time depends on order quantity.

Brand Name TES

Model Number AFLEX-6300

Specifications

Graphic Power Quality Analyzer AFLEX-6300

Display of Overlapped Voltage and Current Waveform
Maximum Demand (MD in W, KW, MW) with Programmable Period
Harmonics Analysis ( V and I ) to the 50th Order
Display of 25 Harmonics in One Screen with Waveform
Display of waveform with Peak Values (512 Samples / Period), Datalogging of 32, 64, 128 or 256 Points/Cycles
Analysis of Total Harmonics Distortion ( % THD-F )
Graphic Phasor Diagram
Programmable PT (1 to 3000) Ratios

Capture 128 Transient Events ( Time + Cycles + Faults ) with Programmable Threshold(%), Can Also be Reviewed in LCD
50000 Records with Programmable Interval ( 1 to 6000 seconds)
Output of Waveform, Power Parameters and 50 Harmonics at Command.
Large Dot Matrix LCD Display with Backlight
Optical Isolated RS-232C Interface
Smart Datalogging to save Battery Power for Long-term Monitoring
Built - in Calendar Clock for Data Logging

AC Watt ( 45 ~ 65 Hz, PF 0.5 to 1, CT=1 )

AC Current (45~65 Hz , True RMS)

Harmonics of ACA in % and Magnitude (1 to 50th order)

Power Factor (PF)

Range	Resolution	Accuracy of Readings
0.00 - 1.00	0.01	± 1.5 % ± 8 digits

Harmonics of AC Voltage in % and Magnitude (1 to 50th order)

Range	Resolution	Accuracy in %	Resolution	Accuracy in Magnitude
50 - 600 V	0.1 %	±0.5%	0.1V	±0.5 % ± 0.5V

General Specification:

Conductor Size	150 mm (approx.)
Battery Type	1.5 V SUM-3 *2
Display	128*64 Dot Matrix
Power Consumption	10 mA (approx.)
Auto - Power - Off	15 minutes
LCD update rate	2 times/sec
Dimension	130mm(L)80mm(W)43mm(H), 5.1"(L)3.1"(W)1.7"(H)
Accessories	Test lead1 pair, Users manual1, Batteries 1.5V*2
No. of Sample / Period	512 ( V & A ), 256 (W)
Operating Temperature	-10 to 50
Operating Humidity	< 85% RH
Storage Temperature	-20 to 60
Storage Humidity	< 75 % RH
Weight	450g
