NEW NDT520 Coating Thickness Gauge Film Thickness Gauge Metal Thickness Gauge
US$ 350 - 550
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
GRAIGAR
Model Number:
NDT520
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
NEW NDT320 High-precision Thickness Gauge Ultrasonic Thickness Meter The Steel Plate Thickness GaugeUS$ 300 - 450MOQ: 1 Piece -
NEW NDT310 Ultrasonic Thickness Gauge Steel Plate Thickness Measurement Meter Wall Thickness Meter Wall InstrumentUS$ 250 - 350MOQ: 1 Piece
-
NEW NDT290S Roll Dedicated Shore Hardness Tester (multi-function)US$ 950 - 1,100MOQ: 1 Piece
-
Bridge Cam Gage Test Ulnar MG-8 Welding Gauge Gage C50 Test Ulnar For Welder InspectionUS$ 18 - 25MOQ: 1 Piece
-
HI-LO Welding Gauge Gage Test Ulnar Welder InspectionUS$ 28 - 35MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
GRAIGAR
Model Number
NDT520
Specifications
NEW NDT520 coating thickness gauge Film thickness gauge Metal thickness gauge
NEW NDT520 coating thickness gauge Film thickness gauge Metal thickness gauge
Product Introduction:
First, the measurement principle:
This instrument uses magnetic detection method for measuring the thickness of non-magnetic material permeable layers on. Magnetic materials generally: steel, iron, silver, nickel high measurement accuracy of this method. Non-destructive detection of the thickness of the magnetic metal substrates (such as steel, iron, alloy, hard magnetic steel, cobalt, nickel) non-magnetic coatings (such as aluminum, chromium, copper, zinc, tin, enamel, rubber, plastics, paint, etc. )
Second, the functional characteristics:
1. Ruby probe: probe wear contact point directly affects the accuracy of the measurement. Ordinary metal contact probe, which will bring great error after surface wear.
2. Set the probe and the host into one, easy to operate
All operations 3. Touch calibration, calibration, measurement, etc.
4. widely used in manufacturing, metal processing industry, chemical industry, commodity inspection and testing fields
5. The project site is particularly suitable for measuring
6. durable, versatile, one-hand operation.
Detailed parameters:
1. Measuring range: 0 ~ 1250um
2. Display accuracy: 1um
3. Minimum measurement area: 10um × 10um
The thinnest matrix: Fe: 0.2mm; NFe: 0.05mm
5. The minimum curvature: convex radius: 5mm; concave radius: 25mm
6. Display: LCD display
7. Power: 4 AAA batteries
8. Weight: 82g (without batteries)
9. Working temperature: -10 - + 60ºC
10. Dimensions: 112 × 69 × 28mm (host).
