Industry API WCB Globe Valve

Industry API WCB Globe Valve thumbnail-1
Industry API WCB Globe Valve photo-1
US$ 30 - 800 MOQ: 1 Set
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Other, Globe
Pressure:
Medium Pressure
Contact Supplier Request Quote Chat Now
Chongqing Hi-Sea Marine Equipment Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Standard or Nonstandard Standard
Structure Other, Globe
Pressure Medium Pressure
Power Other, Manual Operation
Material Other, WCB
Temperature of Media Normal Temperature
Media Other, Water, Gas, Oil
Port Size Class150-1500
Place of Origin Chongqing, China
Model Number N/A
Brand Name HS

Specifications

WCB Globe Valve :
1. Nominal Diameter: 2-16 inch
2. Standard: API
3. Certificate: ISO, API
4. Valve Body: WCB

WCB Globe Valve:

Industry API WCB Globe Valve:

1. Standard:



 Face to Face Dimensions: ANSI B16.10



End Flange Dimensions: ANSI B16.5



Basic Design: API 600& BS 1873



Test Standard: API 598



2. Detailed Information:



Nominal Diameter: 2-16 inch (51-387 mm)



Nominal Pressure: Class150, Class300, Class600, Class900, Class1500



Connection: RF, BW, RTJ



Weight: 19-810 kg



3. Material:







N0.

Part Name

Qty.

Material

  1

Body

  1

WCB

  2

Seat

  2

AIO5+HF

  3

Disc

  1

WCB+F6

  4

Thrust Plate

  1

A276 430

  5

Disc Cover

  1

A276 410

  6

Stem

  1

A182 F6

  7

Gasket

  1

A29 1008

  8

Bonnet

  1

WCB

  9

Bolt



A193 B7

  10

Nut



A194 2H

  11

Pin

  2

A29 1035

  12

Split Pin

  2

A570 Gr.A

  13

Gland Flange

  1

WCB

  14

Eye Blot

  2

A193 B7

  15

Eye Nut

  2

A194 2H

  16

Stem Nut

  1

D-2

  17

Gasket

  1

A276 410

  18

Nut

  1

1035

  19

Hand Wheel

  1

60-40-18

  20

Screw

  1

A29 1035

  21

Gland

  1

A276 410

  22

Packing

  2

Stainless Steel Wire With

  23

Packing

4-5

Flexible Graphite

  24

Distance Ring

  1

A276 410

  25

Back Seat

  1

A276 410

  26

Rivet

  2

304







4. Industry API WCB Globe Valve Drawing:

Industry API WCB Globe Valve

5. Industry API WCB Globe Valve Warehouse:

Industry API WCB Globe Valve
