Product Details
| Place of Origin | Guangdong, China | Brand Name | NOYAFA | |
| Model Number | NF-868W |
Product Description
NOYAFA NF-868W Cable length Tester Wire Tracker Cable Scanner Breakpoint Teste High Quality
Item specifics:
- Brand Name: NOYAFA
- Package: Yes
- Model Number: NF-868W
- Port: RJ11 RJ45 BNC USB
- Battery: 9V (not included)
- Remote units: 8pcs
- Color : Red
- Certificates: CE
Product Description
1. To quickly find the target wire or cable among kinds of wires.
2. Cable tracing on exchanger or Router with power-on.
3. Measure length of network cable, coaxial cable, telephone cable and USB cable
4. Test cable length up to 2000m and locate the short point accurately.
5. To perform crosstalk test on network cable to solve the potential problem of slow speed .
6. Test open, short , cross connection, reverse connection.
7. 8 remote units are included.
8. Functions of storage and memory.
9. Automatic delay power on-off and backlight function
Main Functions:
1. To quickly find the target wire or cable among kinds of wires.
2. Cable tracing on exchanger or Router with power-on.
3. Measure length of network cable, coaxial cable, telephone cable and USB cable
4. Test cable length and locate the short point accurately.
5. To perform crosstalk test on network cable to solve the potential problem of slow speed .
6. Test open, short , cross connection, reverse connection.
7. 8 remote units are included.
8. Functions of storage and memory.
9. Automatic delay power on-off and backlight function.
Technical indexes:
| NF-868W Transmitter specifications | |
| LCD screen | 53x25mm |
| Tone frequency | 225Hz |
| The Max. distance of tracing cable | Electrified wire:3000m Non-electrified wire: 2000m |
| The Max. distance of cablemapping | 2500m |
| The Max. distance of cable length testing | 1000m |
| Trace cable coonected to switch | Anti-jamming |
| Tone mode | 2 Tones, adjustable |
| Compatible with connectors | RJ11,RJ45,BNC,USB |
| LED lights display | Wiremap, tone, tracing |
| Cable map indication | LCD (#1- #8) |
| Shielded indication | LCD (#9) |
| Voltage protection | AC 60V/DC 42V |
| Low battery display | LCD (6.5V) |
| Battery type | DC9.0V NEDA 1604/6F22 DC9V) x 1pc |
| Dimensions (LxWxD) | 185 x 80 x 32mm |
| NF-868W Receiver specifications | |
| Frequency | 225kHz |
| The Max. working current | Less than 70mA |
| Earphone jack | 1 |
| LED illumination | 2 LEDs |
| Battery type | DC9.0V NEDA 1604/6F22 DC9V) x 1pc |
| Dimensions (LxWxD) | 218 x 46 x 29mm |
| NF-868W Remote unit specifications | |
| Remote indentifier | 8 pcs |
| Compatible with connectors | RJ11,RJ45,BNC,USB |
| Dimensions (LxWxD) | 107 x 30 x 24mm |
