Original Noyafa NF-8601W RJ45 LAN Network Cable Tester UTP STP Diagnose Tone Tracer BNC PING/POE RJ11 Telephone Wire Tracker
Main Function:
1. Check the PING , POE and cross-talk functions for Network cable.
2. Hunt the target cable from a bundle of cables , such as RJ11 / RJ45 / BNC.
3. Under the situation of connecting Ethernet switches / router to find target cable.
4. Locate the short circuit location for 2 cores cable.
5. Test the RJ11 , RJ45 , BNC cable length under open circuit.
6. Wiremap the short , open , cross , reverse circuit for RJ11 / RJ45 / BNC cables
Application:
1. 3.7V lithium battery power supply ,Convenient, durable, and durable.
2. 2.8 inches LCD Color screen ,Clear, intuitive and personalization.
3. Mian tester can save and export 160 groups of data.
| Technical indexes: | |
| NF-8601W Transmitter specifications | |
| Indictor | LCD 320x240 mm, with backlight |
| Cable test types | STP/UTP 5E,6E network , telephone , coaxial cable |
| Max. distance of wiremap | 2000 m |
| Max. distance of tracing | 2000m |
| Max. distance of cable length | 1000 m |
| Min. distance of calibration | 10 m |
| Accuracy | 3% ( after calibration ) |
| Compatible connectors | RJ11,RJ45 ,BNC, PING/POE |
| Cable map indication | LCD (#1-#8) |
| Battery Type | 3.7V lithium battery 1800mAh |
| Work temperature / humidity | 10℃ ~ -60℃ / 0℃~70℃ |
| Dimension(LxWxD) | 173x92x34mm |
| NF-8601W Receiver specifications | |
| Cable hunting | RJ11,RJ45, BNC |
| Types of cable | ≥ 2 cores |
| Battery Type | 3.7V lithium battery 1800mAh |
| Dimension(LxWxD) | 183x58x35 mm |
| NF-8601W Remote unit specifications | |
| Compatible connectors | RJ11,RJ45, BNC |
| Remote | 8 |
| Dimension(LxWxD) | 106x32x30mm |
Package List:
