Original Noyafa English version Multi-functional Network Cable Tester LCD Cable length Tester Breakpoint Tester NF-8601A
Main function:
1.Check the PING , POE and cross-talk functions for Network cable.
2. Hunt the target cable from a bundle of cables , such as RJ11 / RJ45 / BNC.
3.Under the situation of connecting Ethernet switches / router to find target cable.
4.Locate the short circuit location for 2 cores cable.
5.Wiremap the short , open , cross , reverse circuit for RJ11 / RJ45 / BNC cables .
Application:
1. 3.7V lithium battery power supply ,Convenient, durable, and durable.
2. 2.8 inches LCD Color screen ,Clear, intuitive and personalization.
3. Mian tester can save and export 160 groups of data.
| Technical indexes: | |
| NF-8601A Transmitter specifications | |
| Indictor | LCD 320x240 mm, with backlight |
| Cable test types | STP/UTP 5E,6E network , telephone, coaxial cable. |
| Max. distance of wiremap | 2000 m |
| Max. distance of length | 1000m |
| Compatible connectors | RJ11, RJ45, BNC, PING/POE |
| Cable map indication | LCD (#1-#8) |
| Battery Type | 3.7V lithium battery 1800mAh |
| Work temperature / humidity | 10℃ ~ -60℃ / 0℃~70℃ |
| Dimension(LxWxD) | 173x92x34mm |
| NF-8601A Remote unit specifications | |
| Compatible connectors | RJ11,RJ45, BNC |
| Dimension(LxWxD) | 106x32x30mm |
Accessories Included:
charger x 1 set
adapted telephone line x 1 set
adapted network cable x 1 set
Cable clips x 1 set
mic USB charger wire x 1 set
toolkit x 1 set
(Julie Zhou)
