Product Details
| Place of Origin | Guangdong, China | Brand Name | MITECH | |
| Model Number | MFD500B | Power | Electronic | |
| Usage | Other, Ultrasonic Flaw Detector |
Product Description
Specifications
MITECH MFD500B PORTABLE DIGITAL ULTRASONIC FLAW DETECTOR APARELHO DE ULTRASSOM
MITECH MFD500B PORTABLE DIGITAL ULTRASONIC FLAW DETECTOR APARELHO DE ULTRASSOM
MFD500B Ultrasonic Flaw Detector is an advanced
digital ultrasonic flaw detector featuring a multi-color TFT LCD and a host of
new features to meet challenging inspection requirements. It combines powerful
flaw detection and measurement capabilities, extensive data storage, and the
ability to transfer detailed inspection data to the PC via its high-speed USB
port..
digital ultrasonic flaw detector featuring a multi-color TFT LCD and a host of
new features to meet challenging inspection requirements. It combines powerful
flaw detection and measurement capabilities, extensive data storage, and the
ability to transfer detailed inspection data to the PC via its high-speed USB
port..
Display
Hi-resolution (320x240 pixels) multi-color TFT LCD with 4
user-selectable
brightness control provides high contrast viewing of the
waveform from bright,
direct sunlight to complete darkness.
The
hi-resolution multi-color TFT LCD display with fast 60 Hz update gives an
“analog look” to the waveform providing detailed information that is
critical in
many applications including nuclear power plant inspections.
Range
Up to 9999 mm in steel. suitable for use on large work pieces and
in
high-resolution measurements.
Pulser
Pulse Energy selectable
among Low, Medium and High.
Pulse Width tunable from 0.1µs to 0.5 µs to
match the probes with different
frequency.
Pulse Repetition Frequency
adjustable from 10 Hz to 1 KHz in 1 Hz increments.
Damping selectable
among 100,200,and 400 for optimum probe
performance
Test Modes include
Pulse echo, dual and thru-transmission
Receiver
Sampling10 digit AD
Converter at the sampling speed of 160 MHz
RectificationPositive Halfwave,
Negative Halfwave, Fullwave and RF
Analog Bandwidth: 0.5MHz to 15MHz
capability with selectable frequency
ranges (automatically set by the
instrument) to match probe for optimum
performance.
Gain0 dB to 110 dB
adjustable in selectable steps 0.1 dB, 2 dB, 6 dB, and locked.
Hi-resolution (320x240 pixels) multi-color TFT LCD with 4
user-selectable
brightness control provides high contrast viewing of the
waveform from bright,
direct sunlight to complete darkness.
The
hi-resolution multi-color TFT LCD display with fast 60 Hz update gives an
“analog look” to the waveform providing detailed information that is
critical in
many applications including nuclear power plant inspections.
Range
Up to 9999 mm in steel. suitable for use on large work pieces and
in
high-resolution measurements.
Pulser
Pulse Energy selectable
among Low, Medium and High.
Pulse Width tunable from 0.1µs to 0.5 µs to
match the probes with different
frequency.
Pulse Repetition Frequency
adjustable from 10 Hz to 1 KHz in 1 Hz increments.
Damping selectable
among 100,200,and 400 for optimum probe
performance
Test Modes include
Pulse echo, dual and thru-transmission
Receiver
Sampling10 digit AD
Converter at the sampling speed of 160 MHz
RectificationPositive Halfwave,
Negative Halfwave, Fullwave and RF
Analog Bandwidth: 0.5MHz to 15MHz
capability with selectable frequency
ranges (automatically set by the
instrument) to match probe for optimum
performance.
Gain0 dB to 110 dB
adjustable in selectable steps 0.1 dB, 2 dB, 6 dB, and locked.
Gates
Gate Start: Variable over entire displayed range
Gate Width: Variable from Gate Start to end of displayed range
Gate
Height: Variable from 0 to 99% Full Screen Height
Alarms: Threshold
positive/negative
Memory
Memory of 100 channel files to store
calibration set-ups
Memory of 1000 wave files to store A-Scan patterns and
instrument settings.
All the files can be stored, recalled and
cleared.
Gate Start: Variable over entire displayed range
Gate Width: Variable from Gate Start to end of displayed range
Gate
Height: Variable from 0 to 99% Full Screen Height
Alarms: Threshold
positive/negative
Memory
Memory of 100 channel files to store
calibration set-ups
Memory of 1000 wave files to store A-Scan patterns and
instrument settings.
All the files can be stored, recalled and
cleared.
Functions
Semiautomatic two point calibration: Automated calibration of
transducer zero offset and/or material velocity
Flaw LocatingLive display
Sound-path, Projection (surface distance),
Depth, Amplitude,
Flaw
sizing: Automatic flaw sizing using AVG/AVG or DAC, speeds reporting of defect
acceptance or rejection.
Digital Readout and Trig. Function:
Thickness/Depth can be displayed in digital readout when using a normal probe
and Peam path, Surface Distance and Depth are directly displayed when angle
probe is in use.
Both the DAC and the AVG method of amplitude evaluation are
available.
Curved Surface Correction feature
Crack Height Measure
function
Weld figure feature
Magnify gatespreading of the gate range
over the entire screen width Video Recording and play Auto-gain
function
Envelope: Simultaneous display of live A-scan at 60 Hz update rate
and envelope of A-scan display
Peak Hold: Compare frozen peak waveforms to
live A-Scans to easily interpret test results.
A Scan FreezeDisplay freeze
holds waveform and sound path data B Scan display feature
Semiautomatic two point calibration: Automated calibration of
transducer zero offset and/or material velocity
Flaw LocatingLive display
Sound-path, Projection (surface distance),
Depth, Amplitude,
Flaw
sizing: Automatic flaw sizing using AVG/AVG or DAC, speeds reporting of defect
acceptance or rejection.
Digital Readout and Trig. Function:
Thickness/Depth can be displayed in digital readout when using a normal probe
and Peam path, Surface Distance and Depth are directly displayed when angle
probe is in use.
Both the DAC and the AVG method of amplitude evaluation are
available.
Curved Surface Correction feature
Crack Height Measure
function
Weld figure feature
Magnify gatespreading of the gate range
over the entire screen width Video Recording and play Auto-gain
function
Envelope: Simultaneous display of live A-scan at 60 Hz update rate
and envelope of A-scan display
Peak Hold: Compare frozen peak waveforms to
live A-Scans to easily interpret test results.
A Scan FreezeDisplay freeze
holds waveform and sound path data B Scan display feature
Real Time Clock
The instrument clock keeps running
tracking the time.
tracking the time.
Communication
High speed USB2.0 port.
The
optional DataPro software helps manage and format stored inspection data for
high-speed transfer to the PC. Data can be printed or easily copied and pasted
into word processing files and spreadsheets for further reporting needs. New
features include live screen capture mode and database tracking.
Battery
Internal rechargeable Li-ion battery pack rated 7.2V at 8800
mAh
8 hours nominal operating time depending on display brightness
8-10 hours typical recharge time
Internal rechargeable Li-ion battery pack rated 7.2V at 8800
mAh
8 hours nominal operating time depending on display brightness
8-10 hours typical recharge time
Knob
Operating adjustments are easily and quickly
made using the rotary knob.
Specifications
Range: 0 to 9999 mm, at steel velocity
Material Velocity: 1000 to 9999m/s
Display Delay: -20 to 3400 µs
Probe Delay/Zero Offset : 0 to 99.99µs
Sensitivity: 110 dB max in
selectable resolution 0.1, 1.0, 2.0, 6.0 dB and locked.
Test Modes: Pulse
echo, dual element and thru-transmission
Pulser: Tunable Square Wave Pulser
Pulse Repetition Frequency ranges from 10 Hz to 1000 Hz
Pulse Energy:
Low, Medium and High
Damping: 100, 200, 400 ohms
Bandwidth (amplifier
bandpass ): 0.5 to 15 MHz
Gate Monitors: Two independent gates controllable
over entire sweep range
Rectification: Positive halfwave, negative halfwave,
fullwave, RF
System Linearity: Horizontal: +/-0.2% FSW, Vertical: 0.25% FSH,
Amplifier
Accuracy +/-1 dB.
Reject (suppression): 0 to 80% full screen
height
Units: Inch or millimeter
Transducer Connections: BNC or
LEMO
Power Requirements: AC Mains 100-240 VAC, 50-60 Hz
Dimensions:
263x170x61 mm (10.4x6.7x2.4 inch)
Operating Temperature: -10 to
50
Storage Temperature: -30 to 50
Material Velocity: 1000 to 9999m/s
Display Delay: -20 to 3400 µs
Probe Delay/Zero Offset : 0 to 99.99µs
Sensitivity: 110 dB max in
selectable resolution 0.1, 1.0, 2.0, 6.0 dB and locked.
Test Modes: Pulse
echo, dual element and thru-transmission
Pulser: Tunable Square Wave Pulser
Pulse Repetition Frequency ranges from 10 Hz to 1000 Hz
Pulse Energy:
Low, Medium and High
Damping: 100, 200, 400 ohms
Bandwidth (amplifier
bandpass ): 0.5 to 15 MHz
Gate Monitors: Two independent gates controllable
over entire sweep range
Rectification: Positive halfwave, negative halfwave,
fullwave, RF
System Linearity: Horizontal: +/-0.2% FSW, Vertical: 0.25% FSH,
Amplifier
Accuracy +/-1 dB.
Reject (suppression): 0 to 80% full screen
height
Units: Inch or millimeter
Transducer Connections: BNC or
LEMO
Power Requirements: AC Mains 100-240 VAC, 50-60 Hz
Dimensions:
263x170x61 mm (10.4x6.7x2.4 inch)
Operating Temperature: -10 to
50
Storage Temperature: -30 to 50
FD500 Standard Configuration
No. | Item | Quantity |
1 | Main Body | 1 |
2 | Straight Beam Probe | 1 |
3 | Angle Probe | 1 |
4 | Machine-probe Cable (Q9-Q9) | 1 |
5 | Battery Module | 1 |
6 | Power Adapter (Charger) | 1 |
7 | Support Pillar | 1 |
8 | Manual | 1 |
9 | Instrument Case | 1 |
10 | Data proceeding Software | 1 |
11 | USB communication Cable | 1 |
Our Services
Contact Us
- Shenzhen Graigar Technology Co., Ltd.
- Contact nameLeo Lee Chat Now
- Phone86-755-27541660
- AddressShajing Street,Baoan District, Shenzhen, Guangdong
Product Categories
New Products
-
MFD350B NDT equipment
-
MFD800C Ultrasonic Flaw Detector NDT detector
-
Digital handheld NDT Flaw Detector MFD500B
-
MFD350B portable Ultrasonic Flaw detector
-
MITECH APARELHO DE ULTRASSOM MFD650C ULTRASONIC FLAW DETECTOR
-
MITECH MFD800C ULTRASONIC FLAW DETECTOR APARELHO DE ULTRASSOM
-
Kairda Digital ultrasonic flaw detector operation instructions KUT650
-
YUT2820 Portable, digital ultrasonic flaw detector
-
ultrasonic flaw detector SUB140
-
ultrasonic flaw detector SUB130
-
Digital Ultrasonic Flaw Detector SUB100
-
ultrasonic flaw detector SUB110
-
MFD350B Ultrasonic Flaw Detector Ultrasonic NDT detector
-
MFD650C Digital Ultrasonic Flaw Detector NDT instruments NDT detector
-
MFD650C Handheld Ultrasonic Flaw Detector
-
Deviser DS2460Q catv meter QAM Analysis Meter
-
NEW S7200 Analog Digital Satellite TV Analyzer DVB-C/T/H/T2/S/S2
-
NEW S7000 Analog Digital Satellite TV Analyzer DVB-C/T/H/T2/S/S2
-
Original Noyafa English version Multi-functional Network Cable Tester LCD Cable length Tester Breakpoint Tester NF-8601A
-
Original Noyafa NF-8601W RJ45 LAN Network Cable Tester UTP STP Diagnose Tone Tracer BNC PING/POE RJ11 Telephone Wire Tracker
-
Original NOYAFA NF-8601 LAN Network Cable Tester Multifunctional Diagnose Tone Tracer BNC PING/POE RJ45 RJ11 Phone Wire Tracker
-
NF-868 Network LAN Phone Tester wire Tracker Cable Length 1200m USB coaxial RJ45
-
Tenmars TM-903 Multimedia LAN cable Tester TM903 handheld Network cable tester of RJ-45, F-Connector
-
High & Low Voltage Wire Tracker NF-820 Underground Cable Finder Anti-Interference Wire Tracker RJ45 RJ11 BNC Tester
Popular Searches
- digital tester
- resistance tester
- electrical instrument
- test instrument
- lab equipment
- analysis instrument
- laboratory instrument
- asphalt mixture mixer
- launch x431 master
- x431
- gloss meter
- resistance meter
- digital instrument
- dc load bank
- testing equipment
- testing machine
- battery load bank
- circuit tester
- impact tester
- lab instrument
- weather station
- gps receiver
- test equipment
- laboratory equipment
- electronic timer
- electronic meter
- electronic instrument
- electricity meter
- data collector
- experiment apparatu
Recommended Products
- Fishing Net Quality Testing Equipment | Tensile Strength & Mesh Resistance Tester
- Sardine Fishing Net Strength Testing Machine | Marine Net Tensile Performance Tester
- Fishing Net Mechanical Strength Tester | Breaking Force & Elongation Testing
- Rope and Net Tensile Testing Equipment | Fishing Net Durability Test Machine
- Nylon & Polypropylene Fishing Net Tensile Testing Machine | Mesh Strength Analyzer
- Sardine Net Tensile Strength Tester | Professional Fishing Net Testing Equipment
- Marine Fishing Net Performance Testing Machine | Elongation & Pull Force Tester
- Fishing Gear Tensile Testing Machine | Mesh & Rope Breaking Strength Tester
- Fishing Net Tensile Strength Testing Equipment for Nylon & Polypropylene Nets
- Sardine Fishing Nets Tensile Testing Machine | Net Strength & Durability Tester
- Concrete/brick compression testing equipment with a one-year warranty
- Tensile and Compression Tester 50kn Universal Testing Machine
Find Similar Products By Category
- Instruments & Meters > Test Instrument > Test Machine
- Please Enter your Email Address
- Please enter the content for your inquiry.
We will find the most reliable suppliers for you according to your description.
Send Now
Shenzhen Graigar Technology Co., Ltd.
AIBot OnlineThis conversation is AI-generated. Contact manufacturer before transaction to confirm info.
-
Leo Lee
Hi there! Welcome to my shop. Let me know if you have any questions.
Your message has exceeded the limit.
- Contact supplier for lowest price
- Customized Request
- Request Sample
- Request Free Catalogs
Your message has exceeded the limit.
-
Purchase Quantity
-
*Sourcing Details
Your inquiry content must be between 10 to 5000 characters.
-
*Email
Please enter Your valid email address.
-
Mobile
