Precision Roughness meter YRT100 ,Surface roughness measurement instrument
Product description
Overview:
Portable roughness tester YRT100 is a pocket-sized portable surface roughness instrument. It has high accuracy, wide measuring range, easy to operate, portable, stable, etc., can be widely used in various metal and nonmetal surface finish testing, the instrument is a sensor host integration pocket instrument, with handheld, it is more suitable for use in the production site.
Characteristics:
*shape with pull aluminum mold design, durable, anti-electromagnetic interference significantly, in line with current design trends.
*DSP processor for high-speed data processing and computing, measurement and computation speed greatly improved.
*the use of the popular liquid crystal display OLED display, high brightness, no viewing angle, wide temperature, for a variety of occasions.
*the use of lithium-ion rechargeable battery, can work long hours, no memory effect, can be operated while charging while working, charging time is short, long battery life.
*use of a common USB interface for charging and communication. Using a dedicated charger or computer USB port for charging, quick and easy.
*dot-matrix liquid crystal display, the interface prompts informative.
*Real-time monitoring of lithium battery and display, a timely reminder of the user charge and the progress with charging tips.
*Auto power off function and low-power hardware and software design of the instrument long working hours, for a variety of field use.
*sensor probe with a protection door, the effective protection of the sensor probe to ensure the accuracy of measurement.
Technical parameters:
measurement parameters (μm): Ra, Rz
Stroke Length (mm): 6
Sample length (mm): 0.25, 0.80, 2.50
Evaluation length (mm): 1.25, 4.0,
Measurement range (μm):
Ra: 0.05 ~ 10.0 Rz: 0.1 ~ 50
Indication error: ± 15%
Indication changing: <12%
sensor stylus tip radius and angle:
Tip radius: 10 μm ± 1 μm
Angle: 90 °
static stylus force measurement sensors and the rate of change:
Static stylus force measurement: ≤ 0.016N
Measuring force change rate: ≤ 800N / m
Head pressure sensor lead: ≤ 0.5N
Battery: 3.7V Li-ion battery
Dimensions: 106 mm × 70 mm × 24 mm
Weight: 200g
Working conditions:
Temperature: -20 ~ 40°c
Relative humidity: <90%
Ambient vibration, non-corrosive media
