YRT200 Portable Digital Surface Roughness Measuring Equipment Tester

Name: YRT200 Portable Digital Surface Roughness Measuring Equipment Tester
Brand: Yatong
SKU: 130802445
Availability: InStock

US$ 1,240 - 1,350 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Yatong

Model Number:

YRT200

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Yatong

Model Number YRT200

Portable digital roughness Tester YRT200

Features

1.Electromechanical integration design, small volume, light weight, easy to use;

2.Using DSP chip to control and data processing, high speed, low power consumption;

3.Large range, parameters RX, Ra, Rz, Rq, Rt, Rp, Rv, R3z, R3y, RzJIS, Rsk, Rku, Rsm, Rmr;

4.128 x 64 OLED dot matrix display, digital / graphic display; highlight no perspective;

5.Display information rich, intuitive, can display all the parameters and graphics;

6.Compatible with ISO, DIN, ANSI, JIS national standards;

7.Built-in lithium ion rechargeable battery and a charging control circuit, high capacity, no memory effect;

8.Residual quantity indicator icon, prompting the user to charge;

9.Display of the charging process instructions, the operator can understand the degree of charge

10.Working time more than 20 hours of continuous work

11.Large capacity data memory, can store 100 groups of original data and waveform.

12.Real-time clock settings and display, convenient data recording and storage

13.With automatic dormancy, automatic shutdown and power saving function

14.Reliable control motor to go dead circuit and software design

15.Measurement information display, menu prompt information, false information and switch machine and other tips that information;

16.Full metal shell design, sturdy, compact, portable, high reliability.

17.Can be in English freely switch

18.Can be connected to a computer and printer;

19.Optional sensor surface, hole sensor, measuring platform, sensor, an extension rod and other accessories.

Technical parameters

Item	Description
The maximum driving trip	17.5mm/0.7inch
Indicating error	Not more than ± 10%
Variation of indication	Not more than 6%
The measured profile	Roughness, waviness, the original contour
Parameter	Ra(0.005μm ~ 16μm), Rz(0.02μm ~ 160μm), Rq, Rx, Rt, Rp, Rv, R3z, R3y, RzJIS, Rsk, Rku, Rsm, Rmr.
Filter	RC,PCRC,Gauss,ISO13565
The sampling length L	0.25mm,0.8mm,2.5mm,8mm
Evaluation length L	(1-5)l
Internal storage capacity	100 groups of original data
External input / output interface	USB
Electric source	Built-in rechargeable lithiumion battery
