VM-6320 Hight Accuracy Vibration Meter Tester NDT Instruments VM6320 (1 to 10KHz) / p-p 0.1-200mm / s0



VM-6320 Hight Accuracy Vibration Meter Tester NDT Instruments VM6320 (1 to 10KHz) / p-p 0.1-200mm / s0





Application:

Used for measuring periodic motion, to check the imbalance and deflecting of moving machinery. Specifically designed for present measuring various mechanical vibration. So as to provide the data for the quality control, run time and equipment upkeep.


Features:



* In accordance with ISO 2954, used for periodic measurements, to detect out-of-balance, misalignment and other mechanical faults in rotating machines.
* Specially designed for easy on site vibration measurement of all rotating machinery for quality control,commissioning, and predictive maintenance purposes.
* Individual high quality ccelerometer for accurate and repeatable measurements.
* Wide frequency range (10Hz~10kHz) in acceleration mode.
* Optional headphones for use as electronic stethoscope.
* Bearing condition monitoring function.
* Use “USB data output” and “RS-232 data output” to connect with PC.
* Provide “Bluetooth ™ data output” choice.




Specification:





 Sensor   Piezoelectric Accelerometer
  Measuring Range
  Acceleration: 0.1~200 m/s⊃2;   Equivalent Peak
  Velocity: 0.01~200 mm/s   True RMS
  Displacement: 0.001~2.0 mm   Equivalent Peak-peak
  Frequency Range   Acceleration: 10 Hz ~ 1k Hz   10 Hz ~ 10k Hz
  Velocity: 10 Hz ~ 1k Hz
  Displacement: 10 Hz ~ 1k Hz
  Accuracy   < 5 %
  Analogue Output   AC Output 0~2.0 V Peak Full Scale (Load Resistance: Above 10k)
  Max. Value Hold
  Power Off   Manual Power Off or Auto Power Off
  Battery Indicator   Low Battery Indicator
  Data Output   USB, RS-232, Bluetooth
  Operating Conditions   Temperature: 0~50 °C Humidity: <90 %RH
  Power Supply   4 x 1.5V AA size (UM-3) Battery
  Dimensions   160 x 68 x 32 mm
  Weight   181 g (Not Including Batteries)







Standard Accessories:



 1. Main Unit

 2. Magnetic Suction Seat

 3. Piezoelectric Transducer

 4. Probe (Cone)

 5. Probe (Spherical)

 6. Carrying Case

 7. Manual Book





Optional Accessories:



 1. Headset

 2. USB, RS-232 data cable with software

 3. Bluetooth data out put with software
