Film / Coating Thickness Gauge Digital Thickness Meter Tester GM220
The compact design performs fast, precise and non-destructive digital coating measurement and plating on steel magnetic conductor. It is widely used on manufacturing, workshop, chemistry or quality control fields.
Features:
LCD display measurement value and status.
Using Hi- sensibility sensor for precise measurement.
0 point, 2 point and basic, three different calibration
methods to make it easy to process the system quick
calibration.
Measure mode: Single, continually and difference .
Data record, recall and delete function.
Data analysis: Average, Maximum, Minimum, standard
deviation, and measure times.
Beep sounds indication.
Low Battery indication.
Auto power off .
LCD backlight .
Simple, compact structure and portable design.
Specification:
Measurement range:
Range Resolution Accuracy
0~1800µm 0.1um/1µm ±(3%H+1)
Suitable for measure non-magnetic coating on magnetic conductor base material.
The minimum curvature radius.
Convex: 2mm Convex: 2 Concave=11 Concave: 11mm
Minimum Sample diameter: 12mm
Minimum Substrate thickness : 0.5mm
LCD display 3 1/2 display
Power supply 9V Alkaline battery
Operation current About 14mA
Battery life Continuously 20 hour .
Auto power off 1 minute
LCD backlight function 7 second.
Operation temperature 0~40?
Operation humidity. 10~95% RH
Low battery indication 7.0V ± 0.2V
Included:
1 x Digital film coating thickness gauge
