Home > Instruments & Meters > Weighing & Measuring Apparatus > Measuring Device > Printer Portable Ultrasonic Thickness Tester/Gauge Leeb352 New Design LED
Printer Portable Ultrasonic Thickness Tester/Gauge Leeb352 New Design LED
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Leeb
Model Number:
Leeb 352
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Leeb451 Portable Digital Surface Roughness Tester Roughness Gauge Ra Rz Rq RtNegotiableMOQ: 1 Piece -
CM8821 New Digital Paint Coating Thickness Meter Gauge F Probes CM-8821NegotiableMOQ: 1 Piece
-
VM-6320 Hight Accuracy Vibration Meter Tester NDT Instruments VM6320 (1 to 10KHz) / P-p 0.1-200mm / s0NegotiableMOQ: 1 Piece
-
New Design Printing Coating Thickness Tester Leeb242 Built-in PrinterUS$ 1 - 370MOQ: 1 Piece
-
Printer Portable Ultrasonic Thickness Tester/Gauge Leeb352 New Design LED Backlight NDF InstrumentsNegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Leeb
Model Number
Leeb 352
Printer Portable Ultrasonic Thickness Tester/Gauge Leeb352 New design LED
Function & Feature:
1,Built in rapid thermal printer.
2,Automatic proofreading zero, on the system error correction.
3, Data transmission: RS232 interface, can be connected to the PC.
4, The unit of measurement, metric, inch optional.
5,A two-point calibration, can improve the accuracy of measurement.
6, Rechargeable Lithium battery.
7, Battery information indicates the rest capacity of the battery,Auto sleep and auto power off function to conserve battery life.
8, Display: LCD with LED backlight .The brightness and the contrast of the LCD is adjustable. And thickness value, coupling condition, power state, CAL calibration state, sound velocity.
9, Able to measure the ultrasonic velocity in turn if the thickness value is known in order to improve the measurement precision.
10,A two-point calibration, can improve the accuracy of measurement.
11, Nonlinear correction, automatic compensation, in order to improve the measurement accuracy.
12, Alarm function: setting the measurement limit and alarming for the results beyond the limit.
13,New design shell.
Application Fields: Widely used in petroleum, chemical industry, metallurgy, shipbuilding, aerospace and other fields.
Measuring Material: Adapted to measure the thickness of good conductor for ultrasonic, such as metal(steel, cast iron, aluminum, copper), plastic, ceramic, glass, glass fiber and so on.
Technical Specification
| Measuring range(mm) | 0.75~350 |
| Resolution(mm) | 0.01 |
| Accuracy(mm) | ±(1%H+0.1) |
| Velocity range(m/s) | 1000~9999 |
| Velocity measurement | √ |
| English Menu | √ |
| LED backlight | √ |
| Operating temperature | 0ºC~40ºC |
| Dampness | 20%~90% |
| Dimensions | 230×86×46mm |
| Power supply | 6V rechargeable Lithium battery |
| Weight | 400g |
| Standard Delivery | Unit Probe Matrix,Probes,Couplant |
| Optional Accessories | Probes,Couplant,Paper for printer |
