Printer Portable Ultrasonic Thickness Tester/Gauge Leeb352 New Design LED

Printer Portable Ultrasonic Thickness Tester/Gauge Leeb352 New Design LED photo-1
Printer Portable Ultrasonic Thickness Tester/Gauge Leeb352 New Design LED photo-2
Printer Portable Ultrasonic Thickness Tester/Gauge Leeb352 New Design LED photo-3
Printer Portable Ultrasonic Thickness Tester/Gauge Leeb352 New Design LED photo-4
Printer Portable Ultrasonic Thickness Tester/Gauge Leeb352 New Design LED photo-5
Printer Portable Ultrasonic Thickness Tester/Gauge Leeb352 New Design LED photo-6
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Leeb
Model Number:
Leeb 352
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name Leeb
Model Number Leeb 352

Printer Portable Ultrasonic Thickness Tester/Gauge Leeb352 New design LED



Printer Portable Ultrasonic Thickness Tester/Gauge Leeb352 New design LED







Function & Feature:

1,Built in rapid thermal printer.
2,Automatic proofreading zero, on the system error correction.
3, Data transmission: RS232 interface, can be connected to the PC.
4, The unit of measurement, metric, inch optional.
5,A two-point calibration, can improve the accuracy of measurement.
6, Rechargeable Lithium battery.
7, Battery information indicates the rest capacity of the battery,Auto sleep and auto power off function to conserve battery life.
8, Display: LCD with LED backlight .The brightness and the contrast of the LCD is adjustable. And thickness value, coupling condition, power state, CAL calibration state, sound velocity.
9, Able to measure the ultrasonic velocity in turn if the thickness value is known in order to improve the measurement precision.
10,A two-point calibration, can improve the accuracy of measurement.
11, Nonlinear correction, automatic compensation, in order to improve the measurement accuracy.
12, Alarm function: setting the measurement limit and alarming for the results beyond the limit.
13,New design shell.


Application Fields:  Widely used in petroleum, chemical industry, metallurgy, shipbuilding, aerospace and other fields.


Measuring Material:  Adapted to measure the thickness of good conductor for ultrasonic, such as metal(steel, cast iron, aluminum, copper), plastic, ceramic, glass, glass fiber and so on.


Technical Specification

Measuring range(mm) 0.75~350
Resolution(mm) 0.01
Accuracy(mm) ±(1%H+0.1)
Velocity range(m/s) 1000~9999
Velocity measurement
English Menu
LED backlight
Operating temperature 0ºC~40ºC
Dampness 20%~90%
Dimensions 230×86×46mm
Power supply 6V rechargeable Lithium battery
Weight 400g
Standard Delivery Unit Probe Matrix,Probes,Couplant
Optional Accessories Probes,Couplant,Paper for printer
