New Slide Digital Surface Roughness Tester Leeb432 connected with PC anf printer
Function & Feature:
l Design of mechanical and electrical integration is adopted to achieve small bulk, light weight.
l Controlled by DSP chip, fast speed of testing with lower consumption and high precision.
l Compatible of ISO/ DIN/ ANSI/ JIS standards.
l Can measure 13 parameters.
l 128× 64 DOT matrix LCD displays all parameters and graphs, DSP chip is used to control and process data with high speed and low power consumption.
l Results are displayed digital/graphically on the LCD, and output to the printer.
l Four filtering methods of RC, PC-RC, GAUSS and D-P,
l Built-in lithium ion chargeable battery,with high capacity and unlimited memory efficiency;
l Continuous working for more than 20 hours.
l English menu operation
l Electric quantity indicator, display the charging process.
l Can store more than 100 groups of measuring data and wave forms.
l Real-time clock setting;
l Low power consumption: Auto sleep, automatic shutdown function of saving energy;
l USB,can be connected with computer and printer.
Application Fields:
l Mechanical processing manufacturing industry, especially metal processing manufacturing.Non-metallic processing and manufacturing.
l Electricity, communications, electronics industry. Such as switches on the coupling, integrated circuits, semiconductor, etc.
l It can measure kinds of machining surface, including: oil pump nozzle matching surface of cylinder head, crankshaft, camshaft, cylinder, cylinder liner, cylinder, piston hole and surface roughness. At the same time can be applied to the PS version of measurement, online detection for setting and adjustment of the machine tool, tool wear loose or machining process.
Technical Specification:
leeb432 | |
Roughness parameter | Ra,Ry,Rq,Rz,Rt,RSm,RS,Rp,Rv,R3z,RSk,Rmax,Rmr |
Resolution | 0.001μm |
Cut-off lengths | 0.25mm / 0.8mm / 2.5mm |
Evaluation length | 1.25mm / 4mm / 5mm |
Standard | ISO,DIN,ANSI,JIS |
Accuracy | ≤±6% |
Repeat ability | <6% |
Sensor | Piezocrystal |
Power supply | 3.7V Lithium-Ion battery |
Operating temperature | 0 ºC -40 ºC |
Weight | 440g |
Dimensions | 119×47×65mm |
Standard configuration | Main Unit,Standard sensor,Model for multi-standard groove,Power adapter |
Optional Accessories | Measurement Platform, printer ,PC analysis software |
(Edited by Julie)
