Specifications
MSO2102A digital oscilloscope 100MHz 2 + 16 channels
MSO2102A digital oscilloscope 100MHz 2 + 16 channels
product feature:
The oledata.mso/DS2000A series digital oscilloscope is 70 MHZ to 300 MHZ
bandwidth, sampling rate is as high as 2 gsa/s, at the same time be both deep
storage depth and high reflection of capture rate high performance general
purpose digital oscilloscope. MSO2000A have 2 + 16 channels, is for the
embedded design and testing of applications in the field of high performance
mixed signal oscilloscope. The oledata.mso/DS2000A series adopted many
of today's advanced technology and process, the overall performance
reached the international advanced level, is the most widely for digital
oscilloscope market including communications, semiconductors, computers,
aerospace defense, instruments and meters, industrial electronics,
consumer electronics, automotive electronics, on-site maintenance,
r&d/education and so on in the field of general design/debug/test
requirements and design of the oscilloscope.
1.Bandwidth of 300 MHZ, with 50 Ω input selection
2.Two analog channel, 16 digital channel (the oledata.mso)
3.Wide range, low noise, vertical sensitivity range: 500 uv/div ~ 10 V/div
4.Real-time sampling rate is as high as 2 g Sa gsa/s/s digital channel 1 (the oledata.mso)
5.Standard storage depth of 14 MPTS, matching up to 56 MPTS standard digital channels for 14 MPTS, matching up to 28 MPTS
6.Waveform capture rate was 50000 per second waveform
7.With as many as 65000 frames of hardware real-time waveform uninterrupted recording and waveform analysis
8.The built-in dual channel, 25 MHz signal source (the oledata.mso/DS2000A - S)
9.Rich trigger and bus decoding function (parallel, RS232, I2C, SPI, CAN)
10.Rich interface: USB Host&Device, LAN (LXI), AUX, USB - GPIB (optional)
11.A novel sophisticated industrial design, convenient operation
12.8 "WVGA (800 x 480), a level 256 waveform grayscale display.
