DG5251 Function/Arbitrary Waveform Generator 250MHz Max.Output Frequency 1GSa/s Max,Sample Rate 128Mpts

Name: DG5251 Function/Arbitrary Waveform Generator 250MHz Max.Output Frequency 1GSa/s Max,Sample Rate 128Mpts
Brand: RIGOL
SKU: 130778711
Availability: InStock

DG5251 Function/Arbitrary Waveform Generator 250MHz Max.Output Frequency 1GSa/s Max,Sample Rate 128Mpts thumbnail-1

DG5251 Function/Arbitrary Waveform Generator 250MHz Max.Output Frequency 1GSa/s Max,Sample Rate 128Mpts photo-1

US$ 8,408 - 8,608 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

RIGOL

Model Number:

DG5251

Contact Supplier Request Quote Chat Now

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name RIGOL

Model Number DG5251

Specifications

DG5251 Function/Arbitrary Waveform Generator 250MHz Max.Output Frequency 1GSa/s Max,Sample rate 128Mpts

Product Description

General Introduction:

DG5000 is a multifunctional generator that combines many functions in one, including Function Generator, Arbitrary Waveform Generator, IQ Baseband Source/IQ IF Source, Frequency Hopping Source (optional) and Pattern Generator (optional). It provides single and dual-channel models. The dual-channel model, with two channels having complete equivalent functions and precisely adjustable phase deviation between the two channels, is a real dual-channel signal generator. DG5000, adopting the Direct Digital Synthesizer (DDS) technology, can provide stable, precise, pure and low distortion signal. The user-friendly interface design and panel layout bring users exceptional experience. Besides, the remote control of the generator can be easily done through different standard configuration interfaces, which provides more solutions for users.

Features and Benefits

4.3 inches, 16M true color TFT LCD
350 MHz, 250 MHz ,100MHz or 70 MHz maximum sine output frequency, 1 GSa/s sample rate, 14 bits resolution
Single/dual-channel models. The dual-channel model supports frequency and phase coupling
The 16+2 channels digital output module (optional) together with the analog channel can rebuild the more mixed signals in daily practice
Support an external power amplifier (optional) that can be configured online
Support frequency hopping output(optional) with hopping interval up to 80 ns and arbitrary editing frequency hopping patterns
14 standard waveform functions: Sine, Square, Ramp, Pulse, Noise, Sinc, Exponential Rise, Exponential Fall, ECG, Gauss, Haversine, Lorentz, Dual Tones and DC
Rise/Fall Time of the Pulse could be adjusted separately
Enable to edit arbitrary waveform up to 512 kpts and output arbitrary waveforms up to 128 Mpts
Support AM, FM, PM, ASK, FSK, PSK and PWM modulations
Support user-defined IQ vector signal modulation and IQ baseband/IF source output
Support Frequency Sweep and Burst output
Abundant I/O: waveform output, synchronous signal output, modulation input, 10 MHz clock input/output, trigger input/output
Enable to store and recall waveform data and instrument state, and support versatile file types
Standard configuration with 1 GBytes flash memory
Plenty of standard interfaces: double USB Hosts, USB Device, LAN, and GPIB (IEEE-488.2)
Seamlessly interconnected with RIGOL USB-TMC digital oscilloscopes for loading and reappearing waveforms
Support USB flash device storage for FAT files
Support PictBridge printer
Provide security lock hole
Support remote control through 10/100M Ethernet web
Conform to LXI-C instrument standards (Version 1.2)
Provide Chinese and English built-in help and input methods
Provide powerful waveform editing PC software
