DS1104Z-S digital oscilloscope 100MHz 4 channel 1GSa/s

DS1104Z-S digital oscilloscope 100MHz 4 channel 1GSa/s

product feature:

The oledata.mso/DS1000Z series digital oscilloscope

The oledata.mso/DS1000Z series digital oscilloscope is 4 channel, 70 MHZ to 100 MHZ

bandwidth, sampling rate is as high as 1 gsa/s, at the same time be both deep storage

depth and takanami capture rate of high-performance economical general digital oscilloscope

. MSO1000Z has 16 digital channel, is for the embedded application in the field of

design and test and launch high-performance economical mixed signal oscilloscope. The

oledata mso/DS1000Z series adopted many of today's advanced technology and

process, the overall performance reached the international advanced level, is the most

widely for digital oscilloscope market including communications, semiconductors,

computers, aerospace defense, instruments and meters, industrial electronics, consumer

electronics, automotive electronics, on-site maintenance, r&d/education and so on in the

field of general design/debug/test requirements and design of the oscilloscope.

1.Analog channel bandwidth: 100 MHZ, 100 MHZ

2.Four analog channel, 16 digital channel (the oledata.mso)

3.Real-time sampling of 1 g Sa/s

4.The standard storage depth 12 MPTS, matching up to 24 MPTS

5.Waveform capture rate was 30000 per second waveform

6.As many as 60000 frames of hardware real-time waveform uninterrupted recording and playback (optional)

7.Rich trigger and the decoding function of the bus

8.Low noise, vertical gear mV/div 1 ~ 10 V/div

9.Built-in 25 MHZ dual channel function/arbitrary wave generator (the oledata.mso/DS1000Z - S)

10.Rich interface: USB Host&Device, LAN (LXI Core Device, 2011), AUX, USB - GPIB (optional)

11.A novel sophisticated industrial design, convenient operation

12.7-inch WVGA (800 x480) TFT screen and multistage waveform grayscale display
