Home > Instruments & Meters > Electronic Instrument > Oscilloscope > Rigol DS1052D 50MHZ With 16-channel Digital Storage Oscilloscope DSO Logic Analyzer
Rigol DS1052D 50MHZ With 16-channel Digital Storage Oscilloscope DSO Logic Analyzer
US$ 500 - 600
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
RIGOL
Model Number:
DS1052D
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Digital Oscilloscope DS1102E 2 Channel 100MHzUS$ 520 - 600MOQ: 1 Piece -
RIGOL DS1102E DS 1102E 2 Channel Digital Oscilloscope 100MHz DSO 1GSa/SUS$ 450 - 500MOQ: 1 Piece
-
Micsig Handheld 200MHz Oscilloscope Tablet Oscilloscope Support Touch Screen Operation MS220T Series 10 Physical MeasurementsUS$ 880 - 950MOQ: 1 Piece
-
Digital Colorful 100MHz 2GSa/s 2Channels Bench Oscilloscope 16Channels Logic Analyzer Multimeter 3in1 USB AC 110-220V UTD4102CUS$ 800 - 1,000MOQ: 1 Piece
-
1GSa/s Real Sampling Rate ,Bandwidth-150MHZ, 2CH+1ext Trig,2Mpts Memory Depth Digital Oscilloscope SDS1152CMLUS$ 660 - 750MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
RIGOL
Model Number
DS1052D
Rigol DS1052D 50MHZ with 16-channel Digital Storage Oscilloscope DSO Logic Analyzer
Product Information:
| DS1052D Digital oscilloscope performance parameters: | ||
Bandwidth | 50 MHz | |
Memory Depth | Single Channel: 1M; Double Channels: 500K | |
| Channels | 2 | |
| Real-time sample rate | Single Channel: 1 GSa/s; Double Channels: 500MSa/s | |
| equivalent sample rate | 25 GSa/s | |
Rise Time | 1.2 ns | |
| Input Impedance | 1 MΩ || 15 pF,50 Ω | |
| Sec/div Range | 2 ns/div - 50 s/div | |
| Lissajous Figures | Bandwidth | 50 MHz |
| phase difference | ± 3° | |
| Trigger Modes | Edge, Pulse, Video, Slope, Delay | |
| Trigger Source | CH1,CH2,Ext,Ext/5,AC Line | |
| Vertical Sensitivity | 2 mV/div -10 V/div | |
| Vertical Resolution | 8bit | |
| Input coupling | DC, AC, GND | |
| Input Max voltage | 300 V (DC + AC Vpp) | |
| Scroll Range | 500 ms/div - 50 s/div | |
| Cursor measure | Manual, Track, Auto | |
| Math | +,-,×,FFT | |
| Storage | Built-in: 10 groups waveforms, 10 groups set up ; USB: bitmap memory, CSV storage, wave set up | |
| Interface | USB Device,USB Host,RS-232,P/F Out (Isolated) | |
Display | 64K TFT Color LCD (320 x 234) | |
Display Language | Multilingual User Interface | |
| Power Source Voltage | 100-240V AC/ 50W Max | |
| Size | 303mm×154mm×133mm(L×H×W) | |
| Weight | Approximately 2.4 kg | |
