OWON HDS1022M-N Handheld Storage Oscilloscope Multimeter 2 Channel 20 MHz Scopemeter 100 MSa/s
US$ 400 - 500
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OWON
Model Number:
HDS1022M-N
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HDS1021M HDS Series Handheld Series Digital Storage OscilloscopeNegotiableMOQ: 1 Piece -
Brand New You Lied UTD1102C 100MHz Handheld Digital Storage Oscilloscope TableUS$ 1,000 - 1,200MOQ: 1 Piece
-
1CH 25MHZ 3.5" LCD 64K Color TFT Portable Digital Oscilloscope UTD1025CLUS$ 300 - 320MOQ: 1 Piece
-
Hantek DSO8060 60M Hz 5-in-1 Handheld Oscilloscope DMM Spectrum AnalyzerUS$ 450 - 500MOQ: 1 Piece
-
Hantek AC/DC Current Clamp CC-65 For DSO3064 KitUS$ 40 - 50MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
OWON
Model Number
HDS1022M-N
OWON HDS1022M-N Handheld Storage Oscilloscope Multimeter 2 Channel 20 MHz Scopemeter 100 MSa/s
HDS-N Series Handheld Series Digital Storage Oscilloscope
+ Main Features
- 2 in 1(DSO+Multimeter)
- Autoscale
- FFT
- 20 automatic measurements
- Bandwidth: 20MHz-100MHz
- Support USB for data transmission to PC
- Replaceable li-ion battery back up (6 hours)
- USB flash disk storage
- Waveform record & replay(HDS2062M-N, HDS3102M-N)
- Dimension: 180mm(L)×115mm(H)×40mm(W)
- Weight: 645g
+ Application
Electronic circuit debugging Circuit testing
Design and manufacture
Education and training
Automobile maintenance and testing
| Model Name | HDS1022M-N | HDS2062M-N | HDS3102M-N | |
| Bandwidth | 20MHz | 60MHz | 100MHz | |
| Sample Rate ( Real time ) | 100MS/s | 250MS/s | 500MS/s | |
| Horizontal Scale(S/div) | 5ns/div~100s/div step by 1~2.5~5 |
5ns/div~100s/div step by 1~2~5 |
||
| Rise time(at input, typical) | ≤17.5ns | ≤5.8ns | ≤3.5ns | |
| Display | 3.7 inch color display with TFT panel(640×480 pixels, 65535 colors) | |||
| Channels | Dual | |||
| Record length | Max. 6000 points on each channel | |||
| Interpolation | (sin x)/x | |||
| Probe attenuation factor | 1X,10X,100X,1000X | |||
| Input coupling | DC, AC, GND |
|||
| DC accuracy(Average) | Average>16:±(5% reading+0.05div) for V | |||
| Vertical Sensitivity | 5mV/div~5V/div (at input) | |||
| Vertical resolution (A/D) | 8 bit(2 channels simultaneously ) | |||
| Max. Input Voltage | 400V (PK-PK) (DC + AC PK-PK, 1MΩ input impedance, Probe attenuation 10:1) CAT II | |||
| Trigger Type | Edge, Video, Alternate | |||
| Trigger Mode | Auto, Normal, Single | |||
| Trigger level | ±6 divisions from screen center | |||
| Acquisition modes | Sample, Peak Detect and Average | |||
| DC gain accuracy | ±3% | |||
| Automatic Measurement | Vpp,Vavg,RMS,Frequency,Period,Vmax,Vmin,Vtop,Vbase,Width,Overshoot ,Preshoot,Risetime,Falltime,+Width,-Width,+Duty,-Duty, Delay A→B, Delay A→B |
|||
| Waveform math | +, -, ×, ÷, FFT | |||
| Waveform storage | 4 waveforms | |||
| Lissajou’s figure |
Bandwidth | 20MHz | 60MHz | 100MHz |
| Phase difference | ±3 degrees | |||
| Communication interface | USB | |||
| Power supply | 100V-240V AC, 50/60Hz | |||
| Li-ion battery | 7.4V, 6 hours operation | |||
| |||||||||||||||||||||||||||||||||||||||||||||
