Home > Instruments & Meters > Electronic Instrument > Oscilloscope > All New Hantek DSO1202BV Digital Handheld Oscilloscope/Multimeter 200MHz

All New Hantek DSO1202BV Digital Handheld Oscilloscope/Multimeter 200MHz

Name: All New Hantek DSO1202BV Digital Handheld Oscilloscope/Multimeter 200MHz
Brand: Hantek
SKU: 130776451

All New Hantek DSO1202BV Digital Handheld Oscilloscope/Multimeter 200MHz thumbnail-1

All New Hantek DSO1202BV Digital Handheld Oscilloscope/Multimeter 200MHz photo-1

US$ 588 - 619 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Hantek

Model Number:

DSO1202BV

Contact Supplier Request Quote Chat Now

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Hantek

Model Number DSO1202BV

All New Hantek DSO1202BV Digital Handheld Oscilloscope/Multimeter 200MHz

Characteristic(Handheld Oscilloscope/Multimete

High Bandwidth 60MHz-200MHz Oscilloscope,1GS/s sample rate, and 6000 Counts DMM with analog bargraph.
Build in Video Help and 2G SD flash memory.
1M Memory Depth.
High Refresh Rate (2500 frames)
Large 5.6 inch TFT Color LCD Display,High Resolution(640*480), Dual-Window Design --More clear, More Detailed
One-touch automatic setup optimizes the position, range, timebase, and triggering to assure a stable display of virtually any waveform
Easy-to-use pop-up menu with built-in multi-language help system
23 Automatic Measurements
Waveform Math: Add, Subtract, Multiply, and Divide
Store and recall over
Automatic cursor tracking measurements
XY Mode
Built-in FFT function converts a time-domain signal into its frequency components to measure harmonic content and distortion in systems
Waveform Recorder to capture/replay input waveforms from CH1 and CH2 with a maximum record length of 1000 frames
Pass-Fail function compares a stored waveform to an unknown input
Average Mode for smoothing waveforms
Square Wave Output (2V, 1kHz) for probe adjustment
USB Host/Device 2.0 full-speed interface ,support removeable disk, LAN Optional ,Easy to control by PC or long-distance.
Dimensions (mm):240(L)x165(W)x50(H), be carried easily.
LabviewVBVC Second Design instance.

Hardware Specification

Model	DSO1202BV	DSO1102BV	DSO1062BV
*Oscilloscope mode*
Bandwidth	200MHz	100MHz	60MHz
Real-time Sample Rate	1GSa/s
Equivalent Sample Rate	25GSa/s
Record Length (Sample Points)	Single-channel: Maximum 1M; Dual-channel: Maximum 512k
SEC/DIV Range	2nS/div-2000S/div (in a 2, 4, 8 sequence)
Delay Time Accuracy	500ps
Video Help	Build in
Flash Memory	Build in 2G SD Card
Vertical
A/D Converter	8-bit resolution
VOLTS/DIV Range	2mV/div~5V/div at input BNC
Position Range	+/-50V(5V/div),+/-40V(2V/div~500mV/div),2V(200mV/div~50mV/div)+/-400mV(20mV/div~2mV/div)
Rise Time at BNC	≤1.7ns	≤3.5ns	≤5.8ns
DC Gain Accuracy	+/-4% for Sample or Average acquisition mode, 5mV/div to 2mV/div +/-3% for Sample or Average acquisition mode, 5V/div to 10mV/div
Trigger
Trigger Sensitivity (Edge Trigger Type)	DC: CH1/CH2(Typical) 1div from DC to 10MHz;1.5div from 10MHz to Full EXT(Typical) 200mV from DC to 40MHz EXT/5(Typical) 1V from DC to 40MHz AC: Attenuates signals below 10Hz HF Reject: Attenuates signals above 80kHz LF Reject: Attenuates signals below 150kHz Noise Reject: Reduces trigger sensitivity
Trigger Level Range	CH1,CH2: +/-8 divisions from center of screen EXT: +/-1.2V EXT/5: +/-6V
Trigger Level Accuracy, typical (Accuracy is for signals having rise and fall times ≥20ns)	CH1,CH2: +/-(0.3div×V/div) (within +/-4 divisions from center of screen)
Hold off Range	100ns-10s
Trigger Type
Edge	Trigger on the rising or falling edge
Pulse Width	Trigger (when >,<,=) on positive or negative pulses Pulse Width Range: 20ns-10s
Video	Trigger on an NTSC, PAL, or SECAM standard video signal Line Range: 1-525 (NTSC), 1-625 (PAL/SECAM)
Slope	Trigger (when >,<,=) on a positive or negative slope Set Time: 20ns–10s
Overtime	from the rising or falling edge Set Time: 20-10s
Alternate	Internal trigger on edge, pulse width, video or slope
Measurement
Cursors	Manual: The difference between voltage cursors ; the difference between time cursors ; calculated by Hz. Tracing: The voltage and time at a waveform point
Automatic	Pk-Pk, Max, Min, Mean, Cyc RMS, Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width
*Meter Mode*
Max. Resolution	6,000 Counts
DMM Testing Modes	Voltage, Current, Resistance, Capacitance, Diode & Continuity
Max. Input Voltage	AC: 600V, DC: 800V
Max. Input Current	AC: 10A, DC: 10A
Input Impedance	10 MΩ
Display
Type	Right angle 5.6 16-digit color LCD
Resolution	640*480 dots
Contrast	16 gears, with the progress bar to show adjustment
Interface	USB host and USB slave, LAN Optional
Power Supply
Voltage	DC Input:12--17VDC, 1500mA
Mechanical
Size	245 x 163 x 52 (mm)
Weight	1.3KG (exclusive of packing and accessories)
