Home > Instruments & Meters > Electronic Instrument > Oscilloscope > Hantek DSO3064A PC USB Based Digital Oscilloscope+Arbitrary Waveform Generator+Spectrum Analysis+Frequency Counter 200MS/s 60MHz
Hantek DSO3064A PC USB Based Digital Oscilloscope+Arbitrary Waveform Generator+Spectrum Analysis+Frequency Counter 200MS/s 60MHz
US$ 370 - 450
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Hantek
Model Number:
dso3064a
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HOT SALE Hantek DSO3064 Automotive Diagnostic Oscilloscope KIT VII 4CH 200MS/s 60MHzUS$ 355 - 400MOQ: 1 Piece -
HOT SALE Hantek1008C 8 Channel PC Virtual Automobile Oscilloscope/data Acquisition Card/ 8 Channel Programmable Signal GeneratorUS$ 80 - 150MOQ: 1 Piece
-
HOT SALE !H050 Hantek1008B 8CH USB Auto Scope/DAQ/8CH Generator 8 Channels Automotive Diagnostic Oscilloscope Hantek 1008BUS$ 80 - 150MOQ: 1 Piece
-
HOT SALE !Hantek1008A 8CH PC Oscilloscope/DAQ/8CH Generator 2.4MSa/s,12bits,10mV/div to 5V/div Input SensitivityUS$ 75 - 150MOQ: 1 Piece
-
HOT SALE ! H041 Hantek DSO-2250 USB PC Based USB Oscilloscope 100MHz 250MS/s 2 Channels Digital OscilloscopeUS$ 210 - 300MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Hantek
Model Number
dso3064a
Hantek DSO3064A PC USB Based Digital Oscilloscope+Arbitrary Waveform Generator+Spectrum Analysis+Frequency Counter 200MS/s 60MHz
PRODUCT DESCRIPTION
Oscilloscope:
4 Channel
200MSa/s real-time sampling rate,10k—16M memory depth per Channel.
Arbitrary Waveform Generator:
25MHz arbitrary waveform output,(sine wave can deliver up to 75MHz) 200MSa/s DDS,12bits of vertical resolution.
Frequency Counter, FFT spectrum analysis.
8--36V Wide range of input voltage, suitable for vehicle power test.
USB 2.0 interface plug and play, LAN and WIFI optional.
More than 20 kinds of automatic measurement function,PASS/FAIL Check function, is suitable for engineering application.
Excellent industrial design, similar interface with bench oscilloscope ,Easy to use.
Software support : Windows NT, Windows 2000, Windows XP ,VISTA,Windows 7.
Supply DEMO code (VC,VB,LABVIEW) and technical support.
8--36V Wide range of input voltage, suitable for vehicle power test.
USB 2.0 interface plug and play, LAN and WIFI optional.
More than 20 kinds of automatic measurement function,PASS/FAIL Check function, is suitable for engineering application.
Excellent industrial design, similar interface with bench oscilloscope ,Easy to use.
Software support : Windows NT, Windows 2000, Windows XP ,VISTA,Windows 7.
Supply DEMO code (VC,VB,LABVIEW) and technical support.
Specifications:
| SPECIFICATIONS | DSO3064A | ||
| Oscilloscope Mode | VERTICAL | Analog Channels | 4 |
| Bandwidth | 60MHz(-3dB) | ||
| Rise Time | 5.8ns | ||
| Input Impedance | Resistance: 1MΩ ; Capacitance: 25 pF | ||
| Input Sensitivity | 10mV/div to 5V/div | ||
| Input Coupling | AC/DC/GND | ||
| Vertical Resolution | 8 bits | ||
| Memory Depth | 10K-16M/CH | ||
| Maximum Input | 400V (DC+AC Peak) | ||
| HORIZONTAL | Real-Time Sampling Rate | 200MS/s | |
| Time BaseRange | 5ns/div to 1000s/div(1-2-5 sequences) | ||
| Time Base Precision | +-50ppm | ||
| TRIGGER | Source | CH1, CH2,CH3,CH4,EXT | |
| Mode | Edge,Pulse,Viedo,Alternative | ||
| X-Y MODE | X-Axis Input | CH1 | |
| Y-Axis Input | CH2 | ||
| Phrase Shift | Max.3 degree | ||
| CURSORS AND MEASUREMENT | Voltage Measurement | Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase, Vavg, Vrms, Vcrms, Preshoot, Overshoot | |
| Time Measurement | Frequency,Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle | ||
| Cursors Measurement | Horizontal ,Vertical, Track, Auto Measure Modes | ||
| Waveform Signal Process | +, - , x, /, FFT, Invert | ||
| AUTO SET | yes | ||
| VOLTAGERANGE | 10mV to 5V/div @ x 1 probe | ||
| 100mV to 50V/div @ x 10 probe | |||
| 1V to 500V/div @ x 100 probe | |||
| 10V to 5000V/div @ x 1000 probe | |||
| 100V to 50000V/div @ x 10000 probe | |||
| 200mV to 100V/div @ 20:1 | |||
| CURRENTRANGE | CC65(20A),CC65(60A),CC650,CC1100 | ||
| CURSOR | Time/frequency difference, voltage difference | ||
| FFT | Rectangular,Hanning,Hamming,Blackman Window | ||
| MATH | Adition,subtraction,multiplication,division | ||
| Arbtrory Wave Form Generator Mode | Waveform Frequency | DC~25MHz | |
| DAC | 2K~200MHz adjustable | ||
| Frequency Resolution | 0.1% | ||
| Channel | 1CH waveform output | ||
| Waveform Depth | 4KSa | ||
| Vertical Resolution | 12 bit | ||
| Frequency Stability | <30ppm | ||
| Wave Amplitude | +-3.5V Max. | ||
| Output Impedance | 50 Ω | ||
| Output Current | 50mA Ipeak=50mA | ||
| System BW | 25M | ||
| Harmonic Distortion | -50dBc(1KHz), -40dBc(10KHz) | ||
| INTERFACE | USB 2.0(Lan ,WIFI Optional) | ||
| POWER SOURCE | 8--36V Wide range of input voltage,suitable for vehicle power test | ||
| MECHANICS | Volume | 255 x 190 x 45 (mm) | |
| Weight | 1Kg | ||
