PC USB Function/Arbitrary Waveform Generator of DDS3005,2.7GHz Frequency Counter thumbnail-1
PC USB Function/Arbitrary Waveform Generator of DDS3005,2.7GHz Frequency Counter photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Hantek
Model Number:
DDS3005
Contact Supplier Request Quote Chat Now
Shenzhen Graigar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Hantek
Model Number DDS3005

PC USB Function/Arbitrary Waveform Generator of DDS3005,2.7GHz Frequency Counter

PC USB Function/Arbitrary Waveform Generator of DDS3005,2.7GHz Frequency Counter

Features

  • 2.7GHz Frequency Counter, PC USB Function/Arbitrary Waveform Generator.
  • It is completely compatible with TEK document format, it can directly read the wavy documents of the oscillograph and the wavy documents edited by TEK wavy editing software to make the its wave reappear.
  • 14bits D/A resolution.
  • USB2.0 interface, no external power source required, easy to use.
  • Automatic calibration.
  • One computer can connect many DDS, extend channel easily.
  • Operating System: Windows 7, Windows Me, Windows NT, Windows 2000, Windows XP, VISTA.
  • LabviewVBVCDelphiC++Build Second Design instance.
Waveform Output Channel
Frequency Range 0.1Hz(DC)~5MHz
Resolution 0.01Hz
DAC Clock 0~50MHz Continuously adjustable, in step of 0.2Hz
Channels 1CH waveform output
Memory Depth 256KSa
Vertical Resolution 14 Bits
Stability <30ppm
Amplitude ±10V Max.
Output Impedance 50 Ω
Output Current 50mA Vpeak=100mA
Low Pass Filter 5MHz, 1MHz, 100KHz, 10KHz, 1KHz Programmable Control
Harmonic Wave distortion -65dBc(1KHz),  -53dBc(10KHz)
Frequency Counter Channel 1
Range DC~25MHz
Input Power 400mVpp~25Vpp
Coupling Mode AC, DC Programmable
Accuracy ±Time Base Error ±1 Count
Input Impedance 50KΩ
Frequency Counter Channel 2
Range 25MHz~2.7GHz
Input Power 400mVpp~25Vpp
Coupling Mode AC
Accuracy ±Time Base Error ±1 Count
Input Impedance 50 Ω
Digital Input and Output
Bits 8 Bits+ Synchronized Signal 1 Bit + External Signal 1 Bit
Level 3/5V  TTL/CMOS
Working Environment
Working Temperature 0~70 Centigrade
Working Humidity 0~65%
Weight 0.7Kg
