OWON VDS3104 PC oscilloscope, 4+1 (multi) Channel and Multi-trigger option 100MHz Bandwidth 1GS/s Sample Rate 5M Record Length

OWON VDS3104 PC oscilloscope, 4+1 (multi) Channel and Multi-trigger option 100MHz Bandwidth 1GS/s Sample Rate 5M Record Length





OWON VDS Series PC oscilloscope
Product Series : VDS Series







Main Features



- Up to 100MHz bandwidth, and max 1GS/sreal-time sample rate
- 10M record length
- Friendly UI : FFT, or X-Y, and waveform 2 views displayed
 on the same screen
- Multi-trigger option : edge, video, slope, pulse, and alternate
- USB isolation - less signal inference, more PC protection
- USB bus powering, and LAN remote control (optional)
- Ultra-thin body design, easy portability



Application



design anddebug



circuitfunction test
education and training











Model

VDS1022I

VDS1022

VDS2052

VDS2062

VDS2064

VDS3102

VDS3104

Bandwidth

25MHz

50MHz

60MHZ

100MHZ

Channel

2+1 (multi)

4+1 (multi)

2+1 (multi)

4+1 (multi)

Sample Rate

100MS/s

250MS/s

500MSa/s

1GSa/s

Horizontal Scale (s/div)

5ns/div~100s/div, step by 1~2~5

2ns/div~100s/div, step by 1~2~5

Rise Time

≤14ns

≤7 ns

≤5.8 ns

≤3.5 ns

Record Length

5K

10M

5M

10M

5M

Input Coupling

DC AC GND

Input Impedance

1MΩ±2%,in parallel with10pF±5pF

Channels Isolation

50Hz : 100 : 1, 10MHz : 40 : 1

Max Input Voltage

400V (PK - PK) (DC+AC, PK - PK)

40V (PK - PK) (DC+AC, PK - PK)

DC Gain Accuracy

±3%

DC Accuracy

Average≥16: ±(3% reading + 0.05div) for T

Probe Attenuation Factor

1X, 10X, 100X, 1000X

LF Respond (AC, -3dB)

≥10Hz (at input, AC coupling, -3dB)

Sampling Rate / Relay Time Accuracy

150ps

Interpolation

sin(x) / x

Interval (T) Accuracy (full bandwidth)

Single: ± (1 interval time + 100ppm × reading + 0.6ns),
Average >16: ±(1 interval time + 100ppm × reading + 0.4ns)

Vertical Resolution (A/D)

8 bits resolution (2 channels simultaneously)

Vertical Sensitivity

5mV/div~5V/div

Trigger Type

Edge, Pulse, Video, Slope, Alternate

Trigger Mode

Auto, Normal, Single

Trigger Level

±5 divisions from screen center

Acquisition Mode

Sample, Peak Detect, and Average

Line / Field Frequency (video)

NTSC, PAL, and SECAM standard

Cursor Measurement

V, and T between cursors

Automatic Measurement

Vpp, Vavg, Vamp, Vrms, Freq, Period, Vmax, Vmin, Vtop, Vbase, Overshoot, Preshoot,
Rise Time, Fall Time, Delay A→B↑, Delay  A→B↓, +Width, -Width, +Duty, -Duty

Waveform Math

+, -, ×, ÷,  FFT

Lissajou`s  Figure

Bandwidth

full bandwidth

Phase Difference

±3 degrees

Communication Interface

USB 2.0

USB 2.0, LAN (optional)

Multi-function Interface

Signal Type

synchronized input / output, Pass / Fail , external trigger input

Level Standard

TTL

Power Supply

5.0V/1A

Power Consumption

≤1.5W

≤5W

Dimensions (W × H × D)

170 × 120 × 18 (mm)

190 × 120 × 18 (mm)

Weight (without package)

About 0.26 kg

About 0.30 kg

(Kelly Liu)
